The Renesas RX65N is a mainstream RX microcontroller with RXv2 core, large-capacity RAM, and enhanced security, connectivity, and human machine interface (HMI) capabilities.
Features
- RXv2 Core 120MHz operation (34 CoreMark/mA), single-precision FPU
- 2.7V to 3.6V operation
- A wide package lineup: 100-pin to 176-pin
- Equipped with various communication interfaces such as Ethernet, USB, CAN, SD host/slave interface, and quad SPI.
- Program Flash up to 2MB, SRAM up to 640KB
- DualBank function convenient for firmware update*1
- HMI
- TFT-LCD controller and 2D drawing engine can reduce CPU load at running of LCD display.*1
Security
- NIST FIPS 140-2 Level 3 CMVP certification*1
- Equipped with Renesas' proprietary hardware secure IP (Trusted Secure IP) that realizes a high level of root-of-trust*1
- Equipped with various encryption engines: AES, TRNG, TDES*1, RSA*1, ECC*1, SHA*1
- Equipped with memory protect functions that protect Flash memory from unintended access to flash
[*1: Only products with 1.5MB or more code flash memory]
NIST: National Institute of Standards and Technology
FIPS: Federal Information Processing Standards
CMVP: Cryptographic Module Validation Program
