RX660

Features

120MHz RXv3 core (6.01 CoreMark/MHz*), single-precision FPU, and register bank save function that speeds up interrupt response
- *Typical for RXv3 core
Trigonometric calculators (sin, cos, arctan, hypot) to speed up motor vector control
Wide operating voltage range of 2.7 to 5.5V
Operating temperature: -40°C to 85°C or -40°C to 105°C
Large-capacity memory: 1MB code flash, 128KB SRAM
32KB data flash that can store data like an EEPROM
Diverse package lineup from 48 to 144 pins
Up to 134 general-purpose I/O ports
CAN FD (ISO 11898-1:2015 compliant, up to 5Mbps transfer)
Infrared remote control receiver circuit
Various other communication interfaces (SCI, IIC, RSPI, etc.)
16-bit PWM timer, 16-bit/32-bit compare match timer, 8-bit timer, RTC
12-bit A/D converter, temperature sensor
Flash memory protection
+/-1.0% accuracy high-speed on-chip oscillator
Pin layout is compatible with existing RX products, peripheral function compatible

Find Other Products in RX 32-Bit Performance/Efficiency MCUs

Pin-Memory Diagram of RX660 standard products

Pin-Memory Diagram of RX660 High-temperature products

High Performance and Noise-Tolerant RX660 MCU for 5V Power Supply

RX660 Block Diagram

Description

The RX660 Group is the first 5V-compatible product among the RX600 and RX700 high-end general-purpose microcontrollers. With this 5V support, it gives excellent noise tolerance and does not require any external coils for noise suppression, which contribute to the reduction of the overall system cost. The RXv3 core operates at 120 MHz with no wait access to the flash memory, resulting in stable arithmetic processing and achieving excellent real-time performance. The number of effective general-purpose IO pins has been increased by approximately 10% from the previous 5V-compatible RX210, enabling an increase in the number of sensors that can be connected with the same package, contributing to easier system upgrades. For peripheral functions, this is the first in the RX series to incorporate CAN FD, enabling the implementation of next-generation networks such as industrial networks. Furthermore, HOCO oscillation accuracy of 1.0% can be guaranteed in a high-end product for the first time, enabling a reduction in external oscillators and contributing to lower system costs. A wide range of customer platform development can be handled with a single chip with a LFQFP package lineup ranging from 48-pin to 144-pin, and featuring up to 1MB flash memory and 128KB SRAM. This easily improves the performance and expands the functionality of home appliances and industrial equipment.

Parameters

Attributes	Value
Main CPU	RXv3
Program Memory (KB)	512, 1024
RAM (KB)	128
Carrier Type	Bulk (Tray), Full Carton (Tray)
Supply Voltage (V)	2.7 - 5.5
I/O Ports	40, 54, 56, 70, 72, 89, 90, 91, 92, 131, 132, 133, 134
DRAM I/F	No
Temp. Range (°C)	Tj = -40 to +105, Tj = -40 to +125
Operating Freq (Max) (MHz)	120
Ethernet speed	No
Ethernet (ch)	0
EtherCat (ch) (#)	0
USB FS (host ch/device ch)	( 0 / 0 )
USB HS (host ch/device ch)	( 0 / 0 )
USB SS (host ch/device ch)	( 0 / 0 )
SCI or UART (ch)	9, 12, 13, 14, 15
SPI (ch)	10, 13, 14, 15, 16
I2C (#)	10, 13, 15, 16, 17
CAN (ch)	0, 1
CAN-FD (ch)	0, 1
Wireless	No
SDHI (ch)	0
High Resolution Output Timer	No
PWM Output (pin#)	21, 24
32-Bit Timer (ch)	2, 3
16-Bit Timer (ch) (#)	11, 12
8-Bit Timer (ch)	3, 4
Standby operable timer	No
12-Bit A/D Converter (ch)	10, 14, 17, 24
24-Bit Sigma-Delta A/D Converter (ch)	0
16-Bit D/A Converter (ch)	0
12-Bit D/A Converter (ch)	2
8-Bit D/A Converter (ch)	0
Capacitive Touch Sensing Unit (ch)	0
Segment LCD Controller	No
Security & Encryption	Unique ID

Package Options

Pkg. Type	Pkg. Dimensions (mm)	Lead Count (#)	Pitch (mm)
LFQFP	7 x 7 x 1.7	48	0.5
LFQFP	10 x 10 x 1.7	64	0.5
LFQFP	12 x 12 x 1.7	80	0.5
LFQFP	14 x 14 x 1.7	100	0.5
LFQFP	20 x 20 x 1.7	144	0.5
