特長
- Cortex-A55(デュアルまたはシングル)
- Cortex-M33
- 3Dグラフィックス機能(Arm® Mali-G31)
- カメラ入力(MIPI-CSI)
- ディスプレイ出力(MIPI-DSI)
- USB 2.0インターフェース 2ch、SDインターフェース 2ch
- CANインタフェース(CAN FD)
- ギガビットイーサネット1ch
- メモリの誤り検出・訂正(ECC)機能
- DDR4あるいはDDR3Lの外部メモリインタフェース
- 13mm角のBGAパッケージ
説明
RZ/G2LCマイクロプロセッサはCortex®-A55(1.2GHz)CPU、16ビットDDR3L/DDR4 インタフェースを備え、3Dグラフィックスエンジンを内蔵しています。また、カメラ入力、ディスプレイ出力、USB 2.0、およびGbit-Etherなどの多くのインターフェースも備えており、エントリークラスの産業用途のヒューマンマシンインタフェース(HMI)や、GUI機能を備えた組込み機器などのアプリケーションに最適です。
ソフトウェアプラットフォームとして, Verified Linux Packageを提供しています.Linux Kernel,ミドルウェア・ドライバ,基本ソフトウェアをパッケージングし,動作検証済みのパッケージとしてルネサスから提供します.(その他のOSにつきましては,ルネサス営業にお問い合わせください)
製品比較
パラメータ
属性 | 値 |
---|---|
CPU Architecture | Arm |
Main CPU | Cortex-A55 x 1 + Cortex-M33 x 1, Cortex-A55 x 2 + Cortex-M33 x 1 |
Program Memory (KB) | 0 |
RAM (KB) | 128 |
Carrier Type | Bulk (Tray), Full Carton (Tray) |
Supply Voltage (V) | 2.97 - 3.63 |
I/O Ports | 57 |
NPU | No |
DRAM I/F | DDR3L-1333, DDR4-1600 (16-bit) |
3D GPU | Arm Mali-G31 |
Temp. Range (°C) | Ta = -40 to +85 |
Operating Freq (Max) (MHz) | 1200 |
Ethernet speed | 10M/100M/1G |
Ethernet (ch) | 1 |
EtherCat (ch) (#) | 0 |
USB FS (host ch/device ch) | ( 2 / 2 ) |
USB HS (host ch/device ch) | ( 2 / 2 ) |
USB SS (host ch/device ch) | ( 0 / 0 ) |
PCI Express (generation and ch) | No |
SCI or UART (ch) | 6 |
SPI (ch) | 3 |
I2C (#) | 4 |
CAN (ch) | 2 |
CAN-FD (ch) | 2 |
Wireless | No |
SDHI (ch) | 2 |
High Resolution Output Timer | No |
PWM Output (pin#) | 0 |
32-Bit Timer (ch) | 10 |
16-Bit Timer (ch) (#) | 7 |
8-Bit Timer (ch) | 0 |
Standby operable timer | No |
Asynchronous General Purpose Timer / Interval Timer (ch) | 0 |
16-Bit A/D Converter (ch) | 0 |
14-Bit A/D Converter (ch) | 0 |
12-Bit A/D Converter (ch) | 0 |
10-Bit A/D Converter (ch) | 0 |
24-Bit Sigma-Delta A/D Converter (ch) | 0 |
16-Bit D/A Converter (ch) | 0 |
12-Bit D/A Converter (ch) | 0 |
10-Bit D/A Converter (ch) (#) | 0 |
8-Bit D/A Converter (ch) | 0 |
Capacitive Touch Sensing Unit (ch) | 0 |
Graphics LCD Controller | No |
MIPI Interfaces (DSI) (ch) | 1 |
MIPI Interfaces (CSI) (ch) | 1 |
Image Codec | No |
Segment LCD Controller | No |
Security & Encryption | AES,RSA,ECC,Hash,TRNG,Arm TrustZone,Secure boot, No |
パッケージオプション
Pkg. Type | Pkg. Dimensions (mm) | Lead Count (#) | Pitch (mm) |
---|---|---|---|
LFBGA | 13 x 13 x 1.4 | 361 | 0.5 |
アプリケーション・ブロック図
|
High-End Central Thermostat
Central thermostat system integrates satellite thermostats for smart climate control and efficiency.
|
|
複数のPHYを備えた産業用IoTゲートウェイ
エッジ処理と豊富な有線および無線インタフェースを備えたスケーラブルなIIoTゲートウェイ。
|
|
バーコードスキャナシステム
デュアルコアCortex-A55ベースのバーコードスキャナは、オブジェクト検出、安全な操作、柔軟な接続性を備えています。
|
|
AIアクセラレータを備えたHMI SoM |
その他アプリケーション
- Industrial HMI+GUI
- Home appliance
- Smart thermostat
- Home security camera
適用されたフィルター
フィルター
ソフトウェア/ツール
サンプルコード
シミュレーションモデル
高性能なHMIを構築するためのワンチップソリューション。Arm® Cortex®-A55と、HMIに必要な全ての機能を内蔵し、AI推論を含む高い処理性能を実現します。
この動画ではRZ/GシリーズのAI BSPを紹介します。
OSSベースのAI BSPによりルネサスRZ/G MPUで簡単にエッジAIを実現可能です。
00:00 Opening
00:10 The Features of RZ/G AI BSP
00:40 RZ/G2 AI Edge AI DEMO
01:00 Pose Estimation
01:50 Face Detection and IRIS Detection
03:10 Closing
関連情報:
Discover how we’re advancing Human Machine Interface (HMI) with edge AI to bring greater efficiency, security, and convenience to businesses and consumers. With our RZ/G2L and RZ/G2LC MPUs, we boost processing performance by 20% and enable native edge AI functionality, supporting popular AI frameworks for seamless integration.
