RL78/G1P

Renesas MCU Guide

Download the mobile app

Overview

The RL78/G1P microcontrollers are only series which have 10-bit D/A converter among general-purpose RL78 lineup besides 12-bit A/D converter. They can be applied for a wide variety of applications such as sensor applications, optical transceivers, etc.

CPU: RL78 core, Max. 32MHz
Voltage: 2.7V to 3.6V
Package: 24-pin HWQFN, 32-pin LQFP
Memory: SRAM Max. 1.5KB, Program Flash Max. 16KB
Timer: 16-bit Timer (ch) x 4, Watchdog Timer (ch) x 1
Serial Interface: CSI (ch) x 1, UART (ch) x 1, I2C (ch) x 1
Analog function: 8/12-bit A/D Converter (ch) x 6 or 8, 10-bit D/A Converter
On-chip Oscillator Freq. (MHz): High-Speed: 32, 24, 16, 12, 8, 6, 4, 3, 2, 1MHz
Others: Clock/Buzzer output, Power-On Reset, Low Voltage Detection

Applications

Office
Home Appliance
Healthcare
Security
Energy Management
