RX72T Group microcontrollers are designed for motor control applications. The max. 200 MHz RXv3 CPU core enables up to 4 inverters to be controlled simultaneously, with advanced security and safety functions for inverter control applications.

Features

  • RXv3 Core 200 MHz operation (5.8 CoreMark/MHz)
  • 2.7 to 5.5 V operation
  • Operating Temperature -40 to 105 °C
  • Program Flash up to 1 MB, SRAM up to 128 KB
  • Dedicated accelerator
    • RXv3 register bank save function
    • Arithmetic unit for trigonometric functions
  • Enhanced Analog
    • 12-bit A/D Converter x 30 channels for 3 units , 12-bit D/A Converter x 2 channels
    • 6-channels of Comparators and 6-channels of Pseudo-Differential PGA
  • 200 MHz PWM
    • 4 channels for 3-phase complementary switching, 2 channels for 5-phase complementary switching, 10 channels for single-phase complementary switching
    • 4-channel high-resolution PWM enables minimum 195 ps timing adjustment
  • Trusted Secure IP Lite (AES/TRNG)

Applications

  • Industrial
  • Office Automation
  • Home appliances

Documentation & Downloads
