The RX Family consists of 32-bit microcontrollers (MCUs) that offers both high performance and low power consumption with a max. 5.8 CoreMark/MHz and max. 44.8 CoreMark/mA.
RX700 (Up to 240MHz) - Prime Series
| Group | Features | Solution |
|---|---|---|
| RX71M | RXv2 core, 240MHz operation, large-capacity ROM/RAM, enhanced connectivity | General Purpose Connectivity Security |
| RX72M | RXv3 CPU, double-precision FPU, 240MHz operation, large capacity ROM/RAM, enhanced connectivity such as EtherCAT and Ethernet/IEEE1588 etc. | Connectivity Security |
RX600 (Up to 160MHz) - High-Speed and High-Performance Series
| Group | Features | Solution |
|---|---|---|
| RX66T | RXv3 core, 160MHz, motor control, digital power control, enhanced safety function, enhanced security function | Motor Control Connectivity Security |
| RX65N, RX651 | RXv2 core, 120MHz operation, large-capacity RAM, enhanced connectivity, security and HMI | General Purpose HMI Connectivity Security |
| RX64M | RXv2 core, 120MHz operation, large-capacity ROM/RAM, enhanced connectivity | General Purpose Connectivity Security |
| RX634 | Up to 54MHz operation, HDMI-CEC and remote control receiving function for linking to home electronics | General Purpose |
| RX631, RX63N | Lineup expanded from RX621/RX62N, added security and image capture functions | General Purpose Connectivity Security |
| RX621, RX62N | 100MHz operation, rich connectivity such as Ethernet, CAN and USB host | General Purpose Connectivity |
| RX630 | 100MHz, general-purpose, large-capacity memory, USB function, comprehensive functions such as 12-bit A/D | General Purpose Connectivity |
| RX63T | For motor and digital power supply control, enhanced safety | Motor Control Connectivity |
| RX62T | For motor and digital power supply control | Motor Control |
| RX62G | For motor and digital power supply control, built-in PWM delay generation function, 5V operation | Motor Control |
RX200 (Up to 80MHz) - Low Power Performance Series
| Group | Features | Solution |
|---|---|---|
| RX24U | RXv2 core, FPU, motor control 32-bit MCU with differential amplifier | Motor Control |
| RX24T | RXv2 core, 32-bit MCU with built-in FPU capable of simultaneously controlling two motors | Motor Control |
| RX23T | RXv2 core, built-in FPU, low power, inherits RX62T functionality | Motor Control |
| RX231, RX230 | RXv2 core, DSP, FPU, external bus function, enhanced security, up to 24 touch channels | General Purpose HMI Connectivity Security |
| RX210 | 1.62V to 5.5V operating voltage, external bus, wide package support: 48 to 145 pins | General Purpose |
| RX220 | Slimmer version of RX210, low power | General Purpose |
| RX21A | For power meters, enhanced analog, encryption, safety | Meter/Measuring |
RX100 (Up to 32MHz) - Ultra-Low Power Series of the RX Family
| Group | Features | Solution |
|---|---|---|
| RX130 | Up to 26 touch channels | General Purpose HMI |
| RX113 | User interface functions for capacitive touch and LCD, built-in USB/IrDA connectivity | General Purpose HMI Connectivity |
| RX111 | Comprehensive low-capacity ROM/low pin count lineup, built-in USB 2.0 | General Purpose Connectivity |
| RX110 | Ideal as sub-MCU of RX MCU system | General Purpose |
RX Family Features
Learn more about the features of the RX Family that allow you to reduce costs, simplify system design, reduce total power consumption, and implement added value.
Development Concept
Learn more about the concept of the RX Family, which concentrates a multitude of Renesas' technologies and aims to be the best 32-bit flash microcontrollers for industrial, home appliance, office automation, and information and communication technology applications.
Peripheral Functions
See an overview of the specifications for each product in the RX Family.
