The ZSC31150KIT Evaluation Kit provides the hardware needed for configuration, calibration and evaluation of the ZSC31150 Sensor Signal Conditioner (SSC) IC. The user's PC can communicate with the ZSC31150 IC socketed on the ZSC31150 SSC Evaluation Board via the SSC Communication Board through a USB connection. The Evaluation Kit Software is available on-line for free download.

The Evaluation Board can connect to the user's sensor or to the SSC Sensor Replacement Board (SRB). The SRB provides a replacement for an actual sensor and can be used for the first step of calibration or a dry-run calibration. On the SRB, the simulated resistive sensor signal is controlled by a potentiometer. The kit also includes the small unpopulated Test Board for facilitating user prototypes.

For further information and support for the SSC Communication Board, visit the SSC-CB product page.

Boards can also be ordered separately. To enable product comparisons, this modular kit is compatible with other select IDT devices. Contact your local sales representative for more information.

Features

  • ZSC31150 Evaluation Board
  • SSC Communication Board
  • SSC Sensor Replacement Board
  • SSC Test Board
  • 5 ZSC31150 samples
  • USB Cable

tuneProduct Options

Part Number Part Status Buy Sample
ZSC31150BOARDV1P2S
Active
Availability
ZSC31150KITV1P2
Active
Availability

descriptionDocumentation

Title language Type Format File Size Date
User Guides & Manuals
star ZSC31150 Evaluation Kit Description Manual - Hardware PDF 1.78 MB
Other
ZSC31150 Bandwidth Calculation Spreadsheet Other XLS 182 KB
ZSC31150 - Tracking and Traceability Technical Brief PDF 180 KB
ZSC31150 Traceability Calculation Spreadsheet Rev. 1.00 Other XLSX 18 KB
ZSC31150 Calibration Calculation Spreadsheet Rev. 2.08 Other XLS 376 KB

file_downloadDownloads

Title language Type Format File Size Date
Software
ZSC31150 Evaluation Kit Software Rev. 2.3.3.0 Software & Tools - Evaluation Software ZIP 4.88 MB
