ZMID5203MLIN

Not Recommended for New Designs

ZMID5203 Inductive Linear Application Module with SENT Output

Order Now
ZMID520x Evaluation Kit User Manual for Application Modules

Overview

The ZMID5203MLIN is an inductive linear position sensor module including sensor PCB, target and target holder.

NOTE: This module is pre-programmed and characterized. For changing programming options, such as motion range or diagnostic settings, the ZMID communication board (ZMID-COMBOARD) is required.

ZMID520x - Linear Evaluation Board (front)
ZMID520x Inductive Linear Position Sensing Modules - Kit Box
ZMID520x Position Sensing Modules COMBOARD - Kit Box
ZMID520x - Linear Evaluation Board (front)
ZMID520x Inductive Linear Position Sensing Modules - Kit Box
ZMID520x Position Sensing Modules COMBOARD - Kit Box
  • Contactless
  • High-resolution linear position measurement
  • Digital SENT output
  • Strayfield-immune

Documentation

Design & Development

Software Downloads

ECAD Models

Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on the CAD Model links in the Product Options table. If a symbol or model isn't available, it can be requested directly from SamacSys.

Explore ECAD Models
Diagram of ECAD Models
