Overview

The RL78/I1D microcontroller has enhanced analog functions such as operational amplifiers, 12-bit A/D converter and window comparators. The MCU also supports very low power operation (124 uA @ 1 MHz) and a high speed 4µs wake up.

  • CPU: RL78 core, Max. 24MHz
  • Voltage: 1.6V to 3.6V
  • Package: 24 to 32-pin QFN, 32 to 48-pin QFP, 20 to 30-pin SOP
  • Memory: SRAM Max. 3KB, Program Flash Max. 32KB
  • Healthcare
  • Human Machine Interface
  • Office Security
