Evaluate Boards Remotely Through an Intuitive GUI

Renesas' Lab on the Cloud is an online environment where Renesas solutions, including popular evaluation boards, winning combinations and software, are hosted in a remote lab that customers access and test online.

The Lab on the Cloud provides quick access to Renesas solutions before customers receive a physical board or start a design. Boards are configured in a remote lab connected to the cloud and users access the boards through an intuitive GUI. Live video of each board allows users to test, monitor, and measure results instantly. The Lab on the Cloud environment utilizes a platform developed by Tenxer Technologies, and provides 24/7 access to, along with online support for, Renesas solutions.

Board Name Description

High Voltage Battery Management System

Start Live Test
This is a battery management solution, for a 20 – 28 cell battery. It has a daisy chain feature, RS-485 to external PC and takes command line interface commands. Learn More

Smart Color Sensing Solution for Pulse Oximeter

Start Live Test
This solution is for pulse oximeter designs, where R, G, B, W values are measured. The mobile app captures data through Bluetooth® Low Energy (LE) and is battery operated. Learn More

GreenPAK Advanced Development Board

Start Live Test
This solution highlights a versatile programmable NVM that integrates many functions into a single custom circuit reducing BOM and power consumption. Learn More

Touchless Sensor Solution

Start Live Test
This solution is suitable for home appliances and provides non-contact touch operation at various programmed distances using the RA2E1 32-bit MCU. Learn More

High Voltage Synchronous Buck-Boost Controller

Start Live Test
This solution uses the ISL81801 synchronous full bridge buck-boost for a wide range (9V – 80V) of input voltage and 100 – 600kHz switching frequencies. Learn More

High Precision Analog Measurement

Start Live Test
This solution shows the integrated analog front end (AFE) of the RX23E MCU and features low noise and low drift for a high precision sensor measurement. Learn More

Mbed™ Based Image Processing Solution

Start Live Test
This image processing solution utilizing the RZ/A2M MPU, featuring an Arm® Cortex®-A9 CPU designed for embedded artificial intelligence (e-AI) based imaging, shows very high-speed processing using Dynamically Reconfigurable Processor (DRP) technology. Learn More

Mini Power Monitor - A Panel Meter Solution

Start Live Test
This mini metering solution accurately measures power consumption, voltage, current, time, and CO2 emission values of electric appliances. Learn More

Power Line Communication

Start Live Test

Demo Video
This solution uses a small PLC modem module to control lighting on a DC power line to show very high speed (1Mbps) communication over a 1km distance. Learn More

RZ/V2M SMARC: Object Detection Solution

Start Live Test
AI-only Accelerator (DRP-AI), 4K-compatible Image Signal Processor (ISP), Vision-AI ASSP for real-time human and object recognition. Learn More

Smart Asset Tracking Label

Start Live Test
The smart asset tracking label is optimized with ultra-low power devices and several standby options for minimal current draw. Learn More

Smart Rangefinder Solution

Start Live Test
This wireless rangefinder measures the distance from an observer to a target and is optimized for handheld applications. Learn More

HMI Solution Board with High-end 32-bit MCU RX Family

Start Live Test
This reference design can be operated via voice command, perform audio playback, and has a GUI display with WQVGA (480x272) on RTOS simultaneously. Learn More

48V Mobility Solution

Start Live Test
A high-voltage powertrain system with modularly integrated wired/wireless charging, a battery management system and optional Bluetooth® wireless connectivity. Learn More

RAJ306010 Prototyping Motor Control Board

Start Live Test
This solution uses a motor control IC for a BLDC vacuum control motor running at 24V, shows efficiency improvement using a self-adaptive dead time feature. Learn More

Clock ICs and Clock Timing Solutions

Start Live Test
An automated system, remotely placed for users to evaluate the phase noise performance of a specific clock configuration on a board using a phase noise analyzer.

Multi-sensor Network Platform for ASI-5

Start Live Test
This solution uses the RA2A1 32-bit MCU and shows Renesas’ unique ASi4U-v5 transceiver chip communicating via an ASi5 bus with multiple sensors. Learn More

RX13T Motor Control Solution

Start Live Test
This BLDC motor control solution shows 24V FOC sensorless and smooth operation using the highly precise IPS2200 inductive position sensor. Learn More

2D Barcode and Face Recognition Evaluation Kit

Start Live Test
A camera solution using the RZ/A2M's high-speed image processing and DRP technology for detecting faces and barcodes, supports an on-board emulator for fast development. Learn More

Precision Weight Scale

Start Live Test
The RX23E MCU's 24-bit ADC precisely (0.1%) measures the weight in this low BOM count solution, which can be used in medical applications. Learn More

Horizone: RA6M3 Evaluation Kit

Start Live Test
This solution that consists of an RA6M3 MCU board with rich connectivity and multiple sensors allows data to be visualized through the Avnet IoTConnect platform's API. Learn More

High Efficiency IoT Battery System

Start Live Test
This cost-effective, wide application solution shows the ISL9122A ultra-low IQ buck-boost regulator, where the output voltage is adjustable using I2C. Learn More

Industrial CAN Sensor Network

Start Live Test
This solution shows the RA2L1 MCU's CAN capability using an isolated RS-485 transceiver to give connection, encryption and decryption between multiple boards and sensors. Learn More

Voice Recognition Solutions

Start Live Test
This reference design recognizes voice commands to initiate a corresponding operation. It uses a high-performance Arm® Cortex®-M4 core-based RA6M1 MCU. Learn More

Capacitive Liquid Level Indicator

Start Live Test
This reference design solution shows water level measurement using a capacitive touch electrode and the capacitive touch sensor unit feature of the RX130 MCU. Learn More

Multi-Purpose Air Quality Sensor Solution

Start Live Test
This is a multi-sensor solution demonstrating indoor air quality (ZMOD4410), outdoor air quality (ZMOD4510) or refrigerator air quality (ZMOD4450). Learn More

FemtoClock®2 Evaluation Board

Start Live Test

Demo Video
An automated system, remotely placed for users to evaluate phase noise performance of a specific clock configuration on a board using a phase noise analyzer. Learn More

Surveillance Camera with CMOS Sensor

Start Live Test
The solution demonstrates a CMOS image sensor (CIS) board with phase-detection autofocus (PDAF) and a high-performance image signal processing (ISP) board. Learn More

IEEE 1588 Solution

Start Live Test
IEEE 1588 solution that demonstrates the clock synchronization up to <50nSec between Master and Slave to reconstruct accurate synchronization signals for 5G networks. Learn More

Household Smoke Detector

Start Live Test

Demo Video
This smoke detector solution using the RAA239101 low-power AFE IC with the RL78/G12 MCU includes peripherals and features for a photoelectric smoke detector system. Learn More

Simplified Contactless Thermometer

Start Live Test
The solution demonstrates a working IR thermometer using analog thermopile sensor functionality in the low power RL78/I1B MCU. Learn More

80V Dual Synchronous Buck Controller Evaluation Board

Start Live Test
This solution shows the transient, line and Load regulation capability of the ISL81802 80V, high voltage, dual synchronous buck controller. Learn More

Supercapacitor Based Terminal Backup Power Supply

Start Live Test
This reference design has a wide input voltage range which supports 4.5V to 40V with 1A to 20A output. It uses a supercapacitor as a backup power supply. Learn More

Flexible MCU-based 6-Channel Power Sequencer

Start Live Test
This reference design allows users to perform two functions, a power-up sequence and a power-down sequence, using the GUI targeted for their specific application. Learn More

MPPT Based Solar Battery Charger

Start Live Test
Solar battery charger with operating range of 8V to 40V, supporting 12V lead acid battery for output currents up to 7A. Learn More

USB PD with Turbo Boost

Start Live Test
This board supports USB Power Delivery (PD) Specification Rev. 3.0 and USB-Type C. The R9A02G011 USB PD controller performs authentication to accept USB Type-C. Learn More

Buck- Boost Last Gasp Power Supply for Energy Meter

Start Live Test
This design uses an ISL85403 synchronous buck or boost-buck controller in the buck-boost configuration to extract power from a supercapacitor (as low as 0.1V). Learn More

Standard 4-20mA Loop - Industrial Receiver

Start Live Test
This board uses a standard 4-20mA loop to transmit data over large distances in industrial environments. It is resistant to surrounding noise. Learn More

Arduino Shield Sensor Board

Start Live Test
This sensor board with an Arduino Shield™ interface is used on interface-equipped microcontroller reference boards and supports multiple sensors. Learn More

Scalable HMI SMARC SoM with AI

Start Live Test
This solution is a Linux-based AI development platform using the RZ/G2 MPU which is suitable for human machine interface (HMI), 3D animation or 4K UHD playback. Learn More

Single Phase Energy Meter

Start Live Test
The single-phase energy meter design is based on the ultra-low power RL78/I1C MCU and is used for single-phase power and energy measurement. Learn More

Digital Illuminometer

Start Live Test
This solution is composed of a 32-bit RA2A1 MCU, an integrated light sensor (ISL29035) and OLED display. It can be used to measure Light Lux levels. Learn More
