The ISL28291EVAL1Z evaluation board is a design platform containing all the circuitry needed to characterize critical performance parameters of the ISL28291 dual op amp, using a variety of user-defined test circuits.
The ISL28291 amplifier is a dual high-speed operational amplifier featuring low noise, low distortion, and rail-to-rail output drive capability. They are designed to operate with single and dual supplies from +5V (±2.5V) down to +3V (±1.5V).
Features
- Operate from a single supply (+3V to +5V)
- Option to operate from split supplies (±1.5V to ±2.5V)
- Each op amp in the dual package is independently configured for differential input
- Each op amp in the dual package is configured for a closed loop gain of 10
