EK-RA6W2 was designed to help us overcome the real challenges of building low-power, secure wireless IoT systems faster and with confidence. By combining a powerful main board with a wireless & Bluetooth® LE daughter card, we enable seamless software development, RF performance evaluation, and cloud connectivity testing on a single platform. Our integrated power measurement circuitry allows us to precisely analyze current consumption, even in low-power sleep modes, so we can optimize battery life early in the design cycle. With microBUS™, Pmod™, and Arduino® Uno connectors, we make it easy to expand, prototype, and validate complete systems using real-world peripherals—all while reducing development risk and time to market.
Features
- Processing & memory:
- Arm® Cortex®‑M33 core running at 160MHz with 704kB SRAM
- 8MB QSPI Flash and 8MB pSRAM for application and data storage
- Wireless connectivity:
- Wi‑Fi® 6 (802.11a/b/g/n/ac/ax) for 2.4GHz and 5GHz operation
- Bluetooth LE 5.1 for short-range, low-power communication
- Peripheral interfaces:
- Multiple serial interfaces, including SPI, UART, I²C, and SDIO 3.0 (device)
- Audio and control support with I²S, PDM, PWM, and a 12‑bit ADC
- System integration:
- Integrated dual‑band antenna to simplify RF design
- Onboard low‑power measurement circuitry to support energy‑efficient design validation
Applications
Documentation
Featured Documentation
Log in required to subscribe
|
|
|
|
|---|---|---|
| Type | Title | Date |
| Manual - Hardware |
PDF
25.66 MB
The EK‑RA6W1 and EK‑RA6W2 evaluation kits provide a comprehensive hardware platform for evaluating RA MCU-based designs. This manual describes system‑level architecture, supported MCU and module variants, and board features, with guidance on configuring jumpers and enabling or disabling hardware functions for efficient evaluation and application development.
|
|
| PCB Design Files | ZIP 5.59 MB | |
| Manual - Development Tools |
PDF
27.18 MB
The EK-RA6W2 evaluation kit is designed to address real-world low-power, secure wireless IoT challenges. It combines a powerful main board with a wireless and Bluetooth LE daughter card to support seamless software development, RF performance evaluation, and cloud connectivity testing on a single platform. The document covers hardware setup, firmware programming, network provisioning, testing, and cross-platform development workflows to accelerate bring-up of RA6W2 MCU-based designs.
|
|
| Certificate |
PDF
443 KB
Describes in conformity with the essential cybersecurity requirements of the relevant Union harmonization legislation, namely the Radio Equipment Directive (RED) 2014/53/EU.
|
|
