RL78/G24 Fast Prototyping Board (RL78/G24 FPB)
The RL78/G24 Fast Prototyping Board is an evaluation board based on the RL78/G24 microcontroller and is specifically designed for prototyping various applications....
New Generation RL78 General-Purpose Microcontrollers with Highest RL78 Processing Performance and Enhanced Analog and Timers
Jump to Page Section:
Overview
Description
The RL78/G24 microcontroller has the highest processing performance of the RL78 family of MCUs, with a CPU operating frequency up to 48 MHz and a flexible application accelerator (FAA). In addition, the enhanced analog functions and an abundance of timers make it a good fit for motor control, power supply, and lighting applications. The FAA is a co-processor dedicated to arithmetic operations, and can be operated independently of the CPU, delivering higher processing power.
A rich development environment is also provided for the RL78/G24, including an evaluation board (Fast Prototyping Board), where simply connecting a USB cable enables program writing/debugging without additional tools, and a kit specialized for initial evaluation of solutions for motors, power supplies, and lighting, and Smart Configurator, which facilitates design using GUI. It is also compatible with the existing RL78 Family and can be a seamless replacement, making it suitable for a wide range of applications from home appliances and consumer electronics to industrial equipment.
Features
- CPU: RL78 core, Max. 48MHz, FAA core
- Voltage: 1.6V to 5.5V
- Package: 20-pin to 64-pin
- Memory: Program Flash: 64/128KB, SRAM 12KB, Data Flash 4KB
- Operating temperature range: up to 125°C
- Timer: 16-bit Timer (ch) x 12, Watchdog Timer (ch) x 1, 32-bit Interval Timer x 1 ch
- PWM: PWM Output x 14
- Analog function: 8/10/12-bit A/D Converter (ch) x 23, 8/10-bit D/A - Converter (ch) x 2~3, Comparator x 4, Programmable gain amplifier (PGA) x 1
- On-chip Oscillator Freq. (MHz):
- High-Speed: up to 64MHz
- Middle-Speed: up to 4MHz
- Low-speed: 32.768kHz
- Event link controller
- Others: RTC, Power-On Reset, Low Voltage Detection
- Packages: SSOP, LQFP, LFQFP, HWQFN, WFLGA
Applications
Applications
- Motor Control
- Power Supply
- Lighting
- General Purpose
- Consumer Applications
- Home Appliances
- Industrial Automation
- Building Automation
