Name: RA8D1 - 480MHz Arm Cortex-M85 Based Graphics Microcontroller with Helium and TrustZone
Brand: Renesas Electronics Corporation
SKU: RA8D1 - 480MHz Arm Cortex-M85 Based Graphics Microcontroller with Helium and TrustZone
Availability: OutOfStock

Features

480MHz Arm^® Cortex^®-M85 with Helium™ MVE
1MB - 2MB Flash memory and 1MB of SRAM including TCM
32KB I/D Caches and 12KB Data Flash
Graphics LCD Controller with RGB and MIPI-DSI I/Fs
2D Drawing Engine, 16-bit CEU Camera I/F
32/16/8-bit external memory interfaces (CS/SDRAM)
ARMv8-M TrustZone^® Security
Renesas Security IP (RSIP-E51A)
On-chip immutable ROM for First Stage Bootloader
xSPI compliant Octal SPI with XIP & DOTF
USB 2.0 HS and FS
2ch of CAN-FD
Ethernet controller with DMA
32-bit & 16-bit Timers, 32-bit Ultra-Low-Power Timer
12-bit ADC and 12-bit DAC
High-Speed Analog Comparators
SCI (UART, Simple SPI, Simple I2C), SDHI, SSI
SPI/ I²C/I³C multi-master interface
Scalable from 176-pin to 224-pin packages

Find Other Products in RA Arm Cortex-M MCUs

RA8D1 480 MHz Arm Cortex-M85 MCUs with Helium™ and TrustZone

Description

The Renesas RA8D1 MCU group features the industry’s first 32-bit graphics-enabled microcontrollers (MCUs) based on the Arm^® Cortex^®-M85 (CM85) core, delivering breakthrough performance of over 3000 CoreMark points at 480MHz and superior graphics capabilities that enable high resolutions display and Vision AI applications. These are general-purpose MCU devices and address diverse high-performance and compute-intensive applications in Industrial Automation, Home Appliances, Smart Home, Consumer, Building/Home Automation, and Medical/Healthcare market segments.

The RA8D1 MCUs integrate the high-performance CM85 core with large memory, and a rich peripheral set including a high-resolution TFT-LCD controller with parallel RGB and MIPI-DSI interfaces, 2D drawing engine, 16-bit camera interface, and multiple external memory interfaces, optimized to address the needs of diverse graphics and Vision AI applications. These MCUs are available in 176 and 224-pin packages. Secure Element-like functionality is built-in with advanced cryptographic Security IP, immutable storage, a true secure boot, and tamper protection, for truly secure IoT.

The RA8D1 MCUs are fully supported by the Flexible Software Package and a comprehensive set of hardware and software development tools.

Parameters

Attributes	Value
Main CPU	Arm Cortex-M85
Program Memory (KB)	1024, 2048
RAM (KB)	1024
Carrier Type	Bulk (Tray), Full Carton (Tray)
Supply Voltage (V)	-
I/O Ports	119, 128, 165, 174
DRAM I/F	SDRAM
Temp. Range (°C)	Tj = -40 to +125
Operating Freq (Max) (MHz)	400, 480
Ethernet speed	10M/100M
EtherCat (ch) (#)	0
USB FS (host ch/device ch)	( 1 / 1 )
USB HS (host ch/device ch)	( 1 / 1 )
USB SS (host ch/device ch)	( 0 / 0 )
SCI or UART (ch)	6
SPI (ch)	2
I2C (#)	2
CAN (ch)	0
CAN-FD (ch)	2
Wireless	No
SDHI (ch)	2
High Resolution Output Timer	No
PWM Output (pin#)	28
32-Bit Timer (ch)	10
16-Bit Timer (ch) (#)	6
Standby operable timer	Yes
Asynchronous General Purpose Timer / Interval Timer (ch)	2
16-Bit A/D Converter (ch)	0
14-Bit A/D Converter (ch)	0
12-Bit A/D Converter (ch)	24, 25
24-Bit Sigma-Delta A/D Converter (ch)	0
12-Bit D/A Converter (ch)	2
8-Bit D/A Converter (ch)	0
Capacitive Touch Sensing Unit (ch)	0
Image Codec	No
Segment LCD Controller	No
Security & Encryption	Unique ID, TRNG, AES, ECC, RSA, SHA224/SHA256, SHA384/SHA512, DOTF, Secure Boot, MAC, SPA/DPA Protection, Tamper Detection, Arm TrustZone

Package Options

Pkg. Type	Pkg. Dimensions (mm)	Lead Count (#)	Pitch (mm)
BGA	13 x 13 x 1.47	224	0.8
LQFP	24 x 24 x 1.4	176	0.5

Application Block Diagrams

	Automatic Espresso Maker with Digital Controls AI-powered espresso machine with a large touchscreen and smart cloud connectivity.
	Ki Wireless Power Transceiver System (Tx) A high-efficiency Ki wireless power transceiver system (Tx) with NFC, smart control, and scalable design.
	Ki Wireless Power Receiver System (Rx) A high-efficiency Ki wireless power receiver system (Rx) with NFC, smart control, and scalable design.
	High-End Feature-Rich HMI Platform Flexible HMI platform with rich feature support for display resolutions, audio, speakers, and more.
	Off-road GPS Guidance System High-accuracy GPS/GNSS system offers precise navigation for agricultural and industrial machinery.
	e-AI-Ready GUI Controller for Appliances and Industrial Systems The e-AI-ready HMI controller offers smart control with AI, predictive maintenance, and rich connectivity.

Additional Applications

Industrial Applications (Industrial HMI, Machine Vision)
Consumer (Video Doorbells, Exercise Equipment, Security Cameras, Appliances)
Smart Home and Building Automation (Thermostats, Security Panels, Home Hubs)
Office Automation (Printer Display, Barcode Scanner, QR Code Reader, Fingerprint Scanner)
Healthcare (Patient Monitors, BP Monitors, Imaging Equipment)
Vision AI Applications (People Detection, Image Classification, Object Detection)
