Micropower Operational Amplifier for GreenPAK™
Jump to Page Section:
Back to top
Explore ECAD Models
Overview
Description
The SLG88104 is a wide voltage range, 375 nA Quad Channel CMOS Input Operational Amplifier capable of rail-to-rail input and output operation. Each Amplifier can be individually powered down.
Features
- Supply Voltage: 1.71 V to 5.5 V
- Low Quiescent Current: 375 nA per Amplifier (typ)
- Rail to Rail Input/Output
- Low Offset Voltage: ±200 µV (typ)
- Low Offset Drift: 1 µV/˚C (typ)
- DC Precision:
- PSRR: 115 dB
- CMRR: 100 dB
- AOL: 120 dB
- Zero-Crossover
- Gain-Bandwidth Product: 10 kHz (typ)
- Industrial Temperature Range: -40 ˚C to 85 ˚C
Applications
Applications
- Battery-Powered Devices
- Portable Devices
- Wearable Products
- Gas Sensors
- Pressure Sensors
- Medical Monitors
- Smoke Detectors
- Active RFID Reader
- Energy Harvester
Documentation
| Title | Type | Date | |
|---|---|---|---|
PDF3.40 MB
|
Datasheet
|
||
PDF974 KB
|
Application Note
|
||
PDF381 KB
|
Application Note
|
||
PDF562 KB
|
Application Note
|
||
PDF490 KB
|
Application Note
|
||
Application Note
|
|||
PDF1.40 MB
|
Application Note
|
||
PDF483 KB Related Files:
|
Application Note
|
||
PDF529 KB Related Files:
|
Application Note
|
||
PDF404 KB Related Files:
|
Application Note
|
||
PDF666 KB Related Files:
|
Application Note
|
||
PDF1.88 MB Related Files:
|
Application Note
|
||
PDF905 KB Related Files:
|
Application Note
|
||
PDF1.19 MB
|
Certificate
|
||
ZIP902 KB
|
White Paper
|
Design & Development
Software & Tools
Boards & Kits
Boards & Kits
SLG88104V Evaluation Board
The SLG88104V-EVB board evaluates the SLG88104 Micropower Operational Amplifier for GreenPAK™.
