Microcontrollers & Microprocessors

Overview

The RL78/F23 next-generation super low-power automotive microcontrollers are ideal to realize future high reliable smart actuators & sensors, as well as low-end body ECUs. As an innovative prolongation of the known RL78/F1x MCUs, the RL78/F23 can cover prospective market requirements. With its increased CPU performance, high temperature capability and an enhanced peripheral feature set, RL78/F23 are a perfect fit for various applications.

RL78/F2x products are designed according to ISO26262 and providing functional safety support up to ASIL-B. They support up to the EVITA-Light security standard or more. An AES crypto module can handle key lengths of up to 256 bits and supports secure boot and authentication. To further boost the calculation performance for BLDC (FOC) motor control and DC/DC control systems, RL78/F2x is equipped with the unique application accelerator IP, to off-load complex trigonometric & arithmetic processing.

RL78/F2x MCUs are fully hard- & software upwards compatible to RL78/F1x, enabling software reuse.

RL78/F2X Block Diagram
RL78/F2X Block Diagram
  • Key Features
    • RL78 core, Max. 40MHz
    • 128KB Flash
    • 12KB RAM
    • 12-bit A/D converter
    • Motor control: DC & BLDC - Field Oriented Control
    • Application accelerator unit
    • Optimized DC/DC converter support
    • High temperature support: up to Ta = 150°C
    • Super low-power consumption
  • State of the Art Interfaces
    • LIN, UART, SPI, I2C, SENT
    • 16 x PWM output
  • Support for FuSa and Security
    • Security module with EVITA-Light support
    • ISO26262 ASIL-B
  • Extensive eco-system supporting the latest standards concerning tool, HW and SW areas
12V Small Motor Solution
Brushless DC Motor Control Solution for Vehicles

Applications

  • Smart actuators
  • Sensors ECUs
  • Low-end body
