Overview
Description
The IDT 89HP0604SB 4-channel SAS / SATA Repeater offers the industry a blend of top analog performance, lower power, and the most system level features in signal repeaters optimized for demanding 1.5Gbps to 6G applications in computing, storage, and communications.
Features
- 4 channel SAS / SATA signal repeater
- Advanced signal conditioning features
- Advanced diagnostic features
- Advanced power saving features
- Built-in mux/demux for Fail-Over support
- Low-cost pin-strapped configuration
- Commercial and Industrial temperature
Design & Development
Boards & Kits
Boards & Kits
Evaluation Board for 89HP0604SB SATA Repeater 2-lane 6Gbps
The 89HP0604SB Repeater Evaluation Board is designed to enable quick in-system testing of IDT’s 4-channel, 6Gbps SATA Repeater IC product.
This board provides a...
Featured Documents:
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Product Options
Processing table
| VFQFPN | 36 | C | Yes | Tray | Get Samples, | |
| VFQFPN | 36 | C | Yes | Reel | ||
| VFQFPN | 36 | I | Yes | Tray | Get Samples, | |
| VFQFPN | 36 | I | Yes | Reel |
