概要
説明
The TSI109 is a host bridge for PowerPC processors that supports PCI-X, DDR2-400 SDRAM, Gigabit Ethernet, and Flash. The device contains numerous integrated features that enable customers to reduce system design complexity and system costs. The TSI109 delivers industry-leading performance for customers in the wireless infrastructure, storage networking, network access, printer, military, and industrial automation markets.
特長
- Processor interface supports MPC74xx and PPC750 processors
- Dual Processor support
- PCI/X Interface supports PCI 2.3 and PCI-X 1.0 modes
- Memory Controller supports DDR2-400 devices
- Integrated bus arbiters for processor and PCI/X devices
- Four independent DMA/XOR channels
- Clock generator with spread-spectrum capability
- Two independent Gigabit Ethernet ports
- HLP Interface for Flash and other simple I/O devices
- Two UARTs
- 16-bit parallel GPIO port
- I2C/EEPROM Interface
- JTAG support (Boundary scan)
- Available in 1023-pin BGA package, which is pin compatible with TSI108
ドキュメント
|
|
日付 | |
|---|---|---|
| PDF 4.34 MB | マニュアル－ハードウェア | |
| PDF 125 KB | 製品変更通知 | |
| PDF 545 KB | EOL通知 | |
| ZIP 604 KB | その他資料 | |
| ZIP 5.70 MB | その他資料 | |
| ZIP 5.16 MB | その他資料 | |
| ZIP 2 KB | その他資料 | |
| ZIP 32 KB | その他資料 | |
| ZIP 4.63 MB | その他資料 | |
| PDF 371 KB | アプリケーションノート | |
| PDF 46 KB | その他資料 | |
| PDF 103 KB | その他資料 | |
| PDF 66 KB | その他資料 | |
| PDF 2.25 MB | マニュアル－ハードウェア | |
| PDF 52 KB | その他資料 | |
| PDF 68 KB | デバイスエラッタ | |
| PDF 69 KB | その他資料 | |
| ZIP 5 KB | その他資料 | |
| PDF 81 KB | 製品概要 | |
