RL78/L1C

Renesas MCU Guide

Download the mobile app

Overview

RL78/L1C microcontrollers have a built-in segment LCD driver and USB 2.0 function. Three LCD driving voltage generation methods (external resistance division, capacitive split, and internal voltage boost) are supported, corresponding to a variety of segment LCD panels. They realize low current consumption^{Note 1}: external resistance division: 1.76 μA^{Note 2}, internal voltage boost: 1.23 μA, and capacitive split: 0.74 µA. They support USB high-speed battery charging (Battery Charging Specification 1.2) and come in a lineup of 80/100-pin, maximum 416 segment products. These microcontrollers can be used in sensor modules and healthcare devices as well as home appliances and measurement devices.

Note 1: Current (typ.) at 1/3 bias, subclock operation, HALT mode, and RTC operation.

Note 2: Resistance value for external resistance division = 1000 kΩ.

CPU: RL78 core, Max. 24MHz
Voltage: 1.6V to 3.6V
Package: 85-pin LGA, 80 to 100-pin QFP
Memory: SRAM Max. 16KB, Program Flash Max. 256KB

High-Performance Electric Vehicle (EV) Charger Wall Box

Applications

Healthcare
Home Appliance
USB
