Overview
Description
The S5D3 adds a new tier to the S5 MCU series for applications that require a high-performance Cortex®-M4F core at a very attractive price point, that does not require on-chip graphic acceleration or Ethernet connectivity. The S5D3 is built on a highly efficient 40nm process, offers enhanced security, wide connectivity, and is fully supported by the Synergy Software Package (SSP).
Commercial software worth over $100K which is available to developers using the Synergy Platform for no charge and with unlimited production license rights. The production-ready SSP is fully tested, maintained, and supported by Renesas.
Features
- 120MHz Arm® Cortex®-M4 CPU
- Optimal for applications that require a high-performance Cortex-M4 core, that does not require on-chip graphic acceleration or Ethernet connectivity
- Available in a variety of packages
- Capacitive Touch Sensing Unit (CTSU)
- High precision data acquisition analog interfaces
- Enhanced security
Comparison
Applications
Design & Development
Software & Tools
Sample Code
Sample Code
Filters
|
||
|---|---|---|
| Type | Title | Date Date |
| Sample Code | ZIP 6.84 MB Compiler: GNUARM-NONE IDE: e2 studio, IAR EW for Synergy | |
| Sample Code | ZIP 6.46 MB Compiler: GNUARM-NONE IDE: e2 studio, IAR EW for Synergy | |
| Sample Code | ZIP 7.40 MB Compiler: GNUARM-NONE IDE: e2 studio, IAR EW for Synergy | |
| Sample Code | ZIP 8.43 MB IDE: e2 studio | |
|
4 items
|
||
Boards & Kits
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on the CAD Model links in the Product Options table. If a symbol or model isn't available, it can be requested directly from SamacSys.
Support
Support Communities
Get quick technical support online from Renesas Engineering Community technical staff.
Resources
Support Communities
-
Is it possible to enable internal reference Voltage for the ADC on the S5D3?
We cannot find the option to enable the Internal Voltage Reference in the ADC120 analog converter on MCU S5D3? Is it possible? thanks in advance.
Oct 6, 2021 -
Working with a SSC slave (3 wire SPI) device using Renesas S5D3
Hello, I have been working with the TB-S5D3 kit for a particular project in my company. I am trying to use the SPI0 interface on this board (as master) to communicate with an SSC slave which has a single data line as shown in the figure below. The slave ...
Jul 15, 2019 -
sdcard on S5D3
I'm new to SD Card, i need sample code where I need to write data to uSD card over SDHI interface (4bits) channel 0.
Sep 12, 2019
FAQs
-
RA Family: Has the data flash correctly erased according to the procedure?
After a data flash area has been erased, the value cannot be read correctly. If read, the value is undefined. Please use the blank check command to check whether the data flash has been correctly erased (blanked).
Jun 17, 2021
