Name: RA6M5 - 200MHz Arm Cortex-M33 TrustZone, Highest Integration with Ethernet and CAN FD
Brand: Renesas Electronics Corporation
SKU: RA6M5 - 200MHz Arm Cortex-M33 TrustZone, Highest Integration with Ethernet and CAN FD
Price: 6.20442 USD
Availability: InStock

Features

200MHz Arm Cortex-M33 with TrustZone
Secure element functionality
1MB - 2MB Flash memory and 448kB SRAM with Parity and 64kB SRAM with ECC
Dual-bank-Flash with background operation, and block swap functionality
8kB Data Flash to store data as in EEPROM
Scalable from 100-pin to 176-pin packages
Ethernet controller with DMA
Capacitive touch sensing unit
USB 2.0 High-Speed and Full-Speed
CAN FD (CAN 2.0B option)
QuadSPI and OctaSPI
SCI (UART, Simple SPI, Simple I²C)
SPI/ I²C multimaster interface
SDHI and MMC

Find Other Products in RA Arm Cortex-M MCUs

RA6M5 200MHz Arm Cortex-M33 MCUs with Extensive Communication Options

Description

The Renesas RA6M5 group uses the high-performance Arm^® Cortex^®-M33 core with TrustZone^®. In concert with the Secure Crypto Engine it offers Secure Element functionality. The integrated Ethernet MAC with individual DMA ensures high data throughput. The RA6M5 is built on a highly efficient 40nm process and is supported by an open and flexible ecosystem concept—the Flexible Software Package (FSP), built on FreeRTOS—and is expandable to use other RTOSes and middleware. The RA6M5 is suitable for IoT applications requiring Ethernet, future proof security, large embedded RAM, and low active power consumption down to 107µA/MHz running the CoreMark^® algorithm from Flash.

Parameters

Attributes	Value
Main CPU	Arm Cortex-M33
Program Memory (KB)	1024, 1536, 2048
RAM (KB)	512
Carrier Type	Bulk (Tray), Full Carton (Tray), Tape & Reel
Supply Voltage (V)	-
I/O Ports	67, 76, 110, 133
DRAM I/F	No
Temp. Range (°C)	Ta = -40 to +85, Ta = -40 to +105
Operating Freq (Max) (MHz)	200
Ethernet speed	10M/100M, No
EtherCat (ch) (#)	0
USB FS (host ch/device ch)	( 1 / 1 )
USB HS (host ch/device ch)	( 0 / 0 ), ( 1 / 1 )
USB SS (host ch/device ch)	( 0 / 0 )
SCI or UART (ch)	9, 10
SPI (ch)	2
I2C (#)	2, 3
CAN (ch)	0, 2
CAN-FD (ch)	0, 2
Wireless	No
SDHI (ch)	1
High Resolution Output Timer	No
PWM Output (pin#)	20
32-Bit Timer (ch)	4
16-Bit Timer (ch) (#)	6
Standby operable timer	Yes
Asynchronous General Purpose Timer / Interval Timer (ch)	6
16-Bit A/D Converter (ch)	0
14-Bit A/D Converter (ch)	0
12-Bit A/D Converter (ch)	17, 19, 22, 26
24-Bit Sigma-Delta A/D Converter (ch)	0
12-Bit D/A Converter (ch)	2
8-Bit D/A Converter (ch)	0
Capacitive Touch Sensing Unit (ch)	6, 12, 20
Image Codec	No
Segment LCD Controller	No
Security & Encryption	128-bit Unique ID, TRNG, AES(128/192/256), ECC/RSA(4K)/DSA, SHA224/SHA256, GHASH, Tamper Detection, Arm TrustZone, Unique ID, TRNG, AES, ECC, RSA, DSA, SHA224/SHA256, Tamper Detection, Arm TrustZone

Package Options

Pkg. Type	Pkg. Dimensions (mm)	Lead Count (#)	Pitch (mm)
BGA	7 x 7 x 1.3	100	0.5
BGA	7 x 7 x 1.29	144	0.5
BGA	13 x 13 x 1.4	176	0.5
LQFP	14 x 14 x 1.7	100	0.5
LQFP	20 x 20 x 1.7	144	0.5
LQFP	24 x 24 x 1.7	176	0.8

Application Block Diagrams

	Highly Secure Drug Delivery System with NFC Authentication and Rich Connectivity Secure drug delivery system with precision dosing and safety features for proper medication and delivery.
	Remote Predictive Maintenance System The remote predictive maintenance system reduces downtime and costs with AI-driven insights and rich connectivity options.
	Wireless Multi-Channel Isolated Data Logger The wireless multi-channel isolated data logger offers multi-channel measurement for industrial networks and Wi-Fi.
	Elevator Control System Elevator control system with integrated real-time communication with main control, in/call, and out/call.
	Embedded Programmable Logic Controller (PLC) for Industrial Use Flexible embedded programmable logic controller (PLC) designed to integrate any type of interface for end-application needs.
	ROS Body Controller for Robotic Systems The centralized ROS body controller simplifies robot coordination with standardized control and efficient communication.
	Smart Voice-Controlled Room Automation Voice recognition enables hands-free control of devices improving hygiene and supporting multilingual commands.
	Fleet Tracking Fleet tracking system with GPS and LTE Cat-M1 for asset monitoring, telematics, transport, and logistics.
	IoT Remote Sensing System Cloud-connected design simplifies secure IoT device linkage and data management with robust connectivity.

Additional Applications

Wired Ethernet applications
Enhanced Security (fire detection, burglar detection, panel control)
Metering (electricity, automated meter reading)
Industry (robotics, door openers, sewing machines, vending machines, UPS)
HVAC (heating, air conditioning, boiler control)
General purpose
