Overview
Description
The RA2E3 group is an entry-line, single-chip microcontroller in the RA family based on the 48MHz Arm® Cortex®-M23 core with up to 64KB code flash and 16KB SRAM memory. RA2E3 MCUs provide an optimized feature set for cost-sensitive applications by supporting pin-to-pin and peripheral compatibility with RA2E1 MCUs. Ultra-low power consumption contributes to energy-efficient system design, required for IoT applications and battery-operated systems to achieve longer battery life.
Features
- 48MHz Arm Cortex-M23 Core
- Up to 64KB flash memory and 16KB SRAM
- 2KB data flash memory (100,000 program/erase (P/E) cycles)
- Package options of 32-pin and 48-pin
- Wide voltage range of 1.6V to 5.5V
- 16-bit general-purpose timers, 32-bit general-purpose timer, and 16-bit low-power asynchronous general-purpose timers
- 12-bit A/D converter and temperature sensor
- SCI (UART, Simple SPI, Simple I2C), SPI, and I2C bus
- Safety functions
Comparison
Applications
Design & Development
Software & Tools
Software & Tools
| Software title
|
Software type
|
Company
|
|---|---|---|
| RA Flexible Software Package (FSP) FSP is an enhanced software package designed to provide easy-to-use, scalable, high-quality software for embedded system designs using Renesas RA Family of Arm Microcontrollers.
Note: FSP with e² studio Installer (Platform Installer) will install the e² studio tool, FSP packs, GCC toolchain, and Segger J-Link drivers required to use this software. No additional installations are required.
|
Software Package | Renesas |
| SEGGER emWin GUI Library for Renesas RA Products SEGGER's emWin graphics library is a ready-to-use solution that provides a versatile and professional GUI platform for creating interactive and high-quality graphical user interfaces on any type of display for the Renesas RA family.
|
Imaging | SEGGER |
| e² studio - information for RA Family Eclipse-based Renesas integrated development environment (IDE).
|
IDE and Coding Tool | Renesas |
| E2 emulator Lite [RTE0T0002LKCE00000R] On-chip debugging emulator. Also available as a flash memory programmer. [Support MCU/MPU: RA, RE, RL78, RX, RISC-V MCU]
|
Emulator | Renesas |
| E2 emulator [RTE0T00020KCE00000R] On-chip debugging emulator. Also available as a flash memory programmer. [Support MCU/MPU: RA, RE, RH850, R-Car D1, RL78, RX, RISC-V MCU]
|
Emulator | Renesas |
| RA Smart Configurator The Renesas RA Smart Configurator (RA SC) is a desktop application that helps you in configuring software systems (including a Board Support Package (BSP), drivers, RTOS, and middleware) for RA-Family MCUs when you are using a third-party IDE and toolchain.
|
Solution Toolkit | Renesas |
| PG-FP6 Flash memory programmer [Programming software: Dedicated GUI-based software, the "FP6 Terminal"] [Support MCU/MPU and devices: RA, RE, RX, RL78, RH850, RISC-V MCU, Renesas Synergy, Power Management, Renesas USB Power Delivery Family, ICs for Motor Driver/Actuator Driver, SuperH RISC engine, V850, 78K, R8C]
|
Programmer (Unit/SW) | Renesas |
| Renesas Flash Programmer (Programming GUI) Flash memory programming software [Support MCU/MPU and devices: RA, RE, RX, RL78, RH850, RISC-V MCU Renesas Synergy, DA1453x, DA1459x, DA1469x, DA1470x, Power Management, Renesas USB Power Delivery Family, ICs for Motor Driver/Actuator Driver, V850, 78K0R, 78K0]
|
Programmer (Unit/SW) | Renesas |
| SEGGER J-Link and J-Trace PRO With their outstanding performance, robustness, and ease of use, J-Link debug probes are widely recognized as the market-leading debug probes today.
|
Emulator | SEGGER |
| IAR Embedded Workbench for Arm IAR Embedded Workbench for Arm (EWARM) provides a complete development environment for Arm, generating fast, compact code and enabling you to take full control of your code.
|
IDE and Coding Tool | IAR Systems |
| Arm® Keil® MDK Arm® Keil® MDK is a comprehensive software development solution for Arm-based microcontrollers, including RA Family MCUs, containing all the components that you need to create, build, and debug embedded applications.
|
IDE and Coding Tool | Arm® Keil® MDK Arm® |
| Reality AI Utilities Round-trip workflow for AI development and performance validation allowing to collect data, optimize models, and deploy directly to Renesas hardware
|
Solution Toolkit | Renesas |
|
12 items
|
||
Sample Code
Boards & Kits
Evaluation
FPB-RA2E3
Active
Fast Prototyping Board for RA2E3 MCU Group
The RA2E3 Fast Prototyping Board comes equipped with an R7FA2E3073CFL microcontroller and is an evaluation board specialized for prototype development for a variety of applications. It has a built-in SEGGER J-Link™ emulator circuit so you can write/debug programs without additional tools. In...
Recommended Documents:
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on the CAD Model links in the Product Options table. If a symbol or model isn't available, it can be requested directly from SamacSys.
Product Options
Applied Filters:
Support
Support Communities
Get quick technical support online from Renesas Engineering Community technical staff.
Support Communities
-
Issue in pin_data.c for RA2E3 with FSP 5.3.0 when using CLKOUT
I was having trouble getting the CLKOUT functioning with the RA2E3 when using FSP 5.3.0 It appears the FSP was not generating the correct code. In pin_data.c the FSP is generating the following code: { .pin = BSP_IO_PORT_01_PIN_09, .pin_cfg = ((uint32_t) IOPORT ...
Jul 2, 2024 -
Upgrading MCU version
Hi Renesas Community, I was working on a project with RA6M1. As I am going a larger version of project I would like to migrate to a MCU with larger code flash memory (2MB). All other features would preserved and new will be added. I would like to get suggestions ...
Mar 24, 2025
FAQs
-
The spec of RA2E3
The RA2E3 group provides optimized feature set for cost-sensitive applications. RA2E3 is cut down version of RA2E1 and we reduced ROM size from 128KB(max) to 64KB(Max), DATA flash size from 4KB to 2KB. Also we removed the functions of comparator, CTSU2, AES, and TRNG. Register configuration and ...
Dec 5, 2023 -
Migration guide from RA2E1 to RA2E3
Renesas provided Application note describing the difference points from hardware and software point view. Highlighting the points to care when migrate from RA2E1 to RA2E3. Otherwise User can easily migrate their design between these groups.
Dec 5, 2023 -
How to handle the MD pin, when using E2 or E2 Lite emulators on a custom RA2 board?
... Hardware RA2E2 Group User's Manual: Hardware RA2A1 Group User's Manual: Hardware RA2E3 Group User's Manual: Hardware RA2A2 Group User's Manual: Hardware E2 Emulator, E2 Emulator Lite Additional Document for User’s Manual (Notes on Connection of RA Devices) Suitable Products RA2E1,RA2L1,RA2E2,RA2A1,RA2E3,RA2A2
Nov 7, 2024
Videos & Training
This video guides first-time users of the RA family using the Fast-Prototyping Board through the steps of installing a development environment, generating a project, and checking the operation to develop software.
The guide features the FPB-RA0E1 (Debugger: J-Link ARM) as a practical example.
