RH850/F1KH-D8

Description

The RH850/F1KH-D8 is one group of single-chip microcontrollers in the RH850/F1x series, which is designed for automotive electrical body applications. While it achieves low power consumption, the internal flash memory ranges from 6MB to 8MB and the package covers a wide range from 176 to 324 pins. Also, CAN FD and Ethernet interfaces, along with a hardware security module have been added to all products, and the CPU operating frequency has been improved to 240MHz and is equipped with a dual CPU.

Parameters

Attributes	Value
Main CPU	G3KH
Program Memory (KB)	6144, 8192
RAM (KB)	896, 1024
Carrier Type	Tray
Supply Voltage (V)	3 - 5.5
I/O Ports	144, 174, 246
DRAM I/F	No
3D GPU	No
Temp. Range (°C)	-40 to +105, -40 to +125
Ethernet speed	100Mb
Ethernet (ch)	1
EtherCat (ch) (#)	0
USB FS (host ch/device ch)	( 0 / 0 )
USB HS (host ch/device ch)	( 0 / 0 )
USB SS (host ch/device ch)	( 0 / 0 )
PCI Express (generation and ch)	No
SCI or UART (ch)	2
SPI (ch)	10
I2C (#)	2
CAN (ch)	8, 12
CAN-FD (ch)	0, 8, 12
Wireless	No
PWM Output (pin#)	0
32-Bit Timer (ch)	16
16-Bit Timer (ch) (#)	48
8-Bit Timer (ch)	0
Standby operable timer	No
Asynchronous General Purpose Timer / Interval Timer (ch)	0
16-Bit A/D Converter (ch)	0
14-Bit A/D Converter (ch)	0
12-Bit A/D Converter (ch)	58, 70
10-Bit A/D Converter (ch)	0
24-Bit Sigma-Delta A/D Converter (ch)	0
16-Bit D/A Converter (ch)	0
12-Bit D/A Converter (ch)	0
10-Bit D/A Converter (ch) (#)	0
8-Bit D/A Converter (ch)	0
Capacitive Touch Sensing Unit (ch)	0
Graphics LCD Controller	No
MIPI Interfaces (CSI) (ch)	0
Image Codec	No
Segment LCD Controller	No
Security & Encryption	Yes

Package Options

Pkg. Type	Pkg. Dimensions (mm)	Lead Count (#)	Pitch (mm)
BGA233	15 x15 x 1.9	233	0.8
BGA324	19 x 19 x 1.9	324	0.8
QFP176	24 x 24 x 1.7	176	0.5

Applications

Car Body
Body control module (BCM)
Automotive gateway
Automotive HVAC
Automotive lighting modules

Part Number	Status	Samples	Stock	RoHS	Package	Carrier Type	Family Name	Series Name	Group Name	CPU Architecture	Main CPU	Sub CPU	Floating Point Unit	Bit Length	Program Memory (KB)	Data Flash (KB)	RAM (KB)	ECC SRAM	Lead Count (#)	Pitch (mm)	Pkg. Dimensions (mm)	Number of Supply Voltage(s) (#)	Supply Voltage (V)	I/O Ports	DMAC or DTC	DMA (ch)	Power-On Reset	Watchdog Timer (ch)	DRAM I/F	3D GPU	Accelerator	MOQ	Temp. Range (°C)	External Interrupt Pins (#)	LVD or PVD	Operating Freq (Max) (MHz)	Sub-clock (32.768 kHz)	On-chip Oscillator	Ethernet speed	Ethernet (ch)	USB FS (host ch/device ch)	USB HS (host ch/device ch)	USB SS (host ch/device ch)	PCI Express (generation and ch)	SCI or UART (ch)	SPI (ch)	OSPI (ch)	I2C (#)	CAN (ch)	CAN-FD (ch)	Wireless	IrDA	LIN (#)	32-Bit Timer (ch)	16-Bit Timer (ch) (#)	Standby operable timer	RTC	12-Bit A/D Converter (ch)	OPAMP (ch) (#)	Graphics LCD Controller	Image Codec	2D Drawing Engine	Segment LCD Controller	Security & Encryption	Moisture Sensitivity Level (MSL)	Camera I/F (Parallel)
R7F7017083AFP-C	Active	N/A	Out of Stock	Contact	LFQFP		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	6144KB	256KB	896KB	Yes	176#	0.5mm	24 x 24 x 1.7	2#	3 - 5.5	144	Yes	32	Yes	1	No	No	No		-40 to +105	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10	0	2#	8	0	No	No	18#	16	48#	No	Yes	58	0	No	No	No	No	Yes	3
R7F7017093AFP-C#AA1	Active	Available	Out of Stock	RoHS:EN RoHS:JA	LFQFP	Tray	RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	8192KB	256KB	1024KB	Yes	176#	0.5mm	24 x 24 x 1.7	2#	3 - 5.5	144	Yes	32	Yes	1	No	No	No	1	-40 to +105	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10	0	2#	8	0	No	No	18#	16	48#	No	Yes	58	0	No	No	No	No	Yes	3
R7F7017103ABG-C	Active	N/A	Out of Stock	Contact	FBGA		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	6144KB	256KB	896KB	Yes	233#	0.8mm	15 x15 x 1.9	2#	3 - 5.5	174	Yes	32	Yes	1	No	No	No		-40 to +105	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10	0	2#	8	8	No	No	20#	16	48#	No	Yes	70		No	No	No	No	Yes	3	No
R7F7017104ABG-C	Active	N/A	Out of Stock	Contact	FBGA		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	6144KB	256KB	896KB	Yes	233#	0.8mm	15 x15 x 1.9	2#	3 - 5.5	174	Yes	32	Yes	1	No	No	No		-40 to +125	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10	0	2#	8	8	No	No	20#	16	48#	No	Yes	70		No	No	No	No	Yes	3	No
R7F7017113ABG-C	Active	N/A	Out of Stock	Contact	FBGA		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	8192KB	256KB	1024KB	Yes	233#	0.8mm	15 x15 x 1.9	2#	3 - 5.5	174	Yes	32	Yes	1	No	No	No		-40 to +105	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10	0	2#	8	8	No	No	20#	16	48#	No	Yes	70		No	No	No	No	Yes	3	No
R7F7017114ABG-C	Active	N/A	Out of Stock	Contact	FBGA		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	8192KB	256KB	1024KB	Yes	233#	0.8mm	15 x15 x 1.9	2#	3 - 5.5	174	Yes	32	Yes	1	No	No	No		-40 to +125	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10	0	2#	8	8	No	No	20#	16	48#	No	Yes	70		No	No	No	No	Yes	3	No
R7F7017143ABG-C	Active	N/A	Out of Stock	Contact	BGA324		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	6144KB	256KB	1024KB	Yes	324#	0.8mm	19 x 19 x 1.9	2#	3 - 5.5	246	Yes	32	Yes	1	No	No	No		-40 to +105	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10		2#	12	12	No	No	24#	16	48#	No	Yes	70		No	No	No	No	Yes	3
R7F7017144ABG-C	Active	N/A	Out of Stock	Contact	BGA324		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	6144KB	256KB	896KB	Yes	324#	0.8mm	19 x 19 x 1.9	2#	3 - 5.5	246	Yes	32	Yes	1	No	No	No		-40 to +125	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10		2#	12	12	No	No	24#	16	48#	No	Yes	70		No	No	No	No	Yes	3
R7F7017153ABG-C	Active	N/A	Out of Stock	Contact	BGA324		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes	32	8192KB	256KB	1024KB	Yes	324#	0.8mm	19 x 19 x 1.9	2#	3 - 5.5	246	Yes	32	Yes	1	No	No	No		-40 to +105	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10		2#	12	12	No	No	24#	16	48#	No	Yes	70		No	No	No	No	Yes	3
R7F7017154ABG-C	Active	N/A	Out of Stock	Contact	BGA324		RH850	RH850/F1x	F1KH-D8	RH850	G3KH	No	Yes		8192KB	256KB	1024KB	Yes	324#	0.8mm	19 x 19 x 1.9	2#	3 - 5.5	246	Yes	32	Yes	1	No	No	No		-40 to +125	24#	Yes	240MHz	Yes	Yes	100Mb	1ch	( 0 / 0 )	( 0 / 0 )	( 0 / 0 )	No	2	10		2#	12	12	No	No	24#	16	48#	No	Yes	70		No	No	No	No	Yes	3
