Renesas' radiation hardened, high-speed, CMOS/SOS logic family includes several buffer/line drivers that are qualified to QML Class V space standards.
Rad Hard Buffer/Line Drivers
Jump to Page Section:
Product Selection Table
Processing table
High Dose Rate (HDR) (krad (Si)) |
Low Dose Rate (LDR) (krad (Si)) |
DSEE (SEL, SEB, etc.) (MeV*cm2/mg) |
DLA SMD |
Qualification Level |
|
|---|---|---|---|---|---|
| Part Number | |||||
| CMOS Non-Inverting Octal Buffer/Line Driver, Three-State | 300 | ELDRS free | SEL free | 5962F9671002V9A | QML Class V (space) |
| CMOS Octal Buffer/Line Driver, Three-State, Inverting | 300 | ELDRS free | SEL free | 5962F9671701VXC | QML Class V (space) |
| CMOS Hex Buffer/Converter | 100 | ELDRS free | 75 | 5962R9663601V9A, 5962R9663601VEC, 5962R9663601VXC, 5962R9663602VXC | QML Class V (space) |
| CMOS Hex Buffer | 100 | ELDRS free | 75 | 5962R9664301VEC, 5962R9664301VXC | QML Class V (space) |
| CMOS Octal Buffer/Line Driver, Three-State, Inverting | 200 | ELDRS free | SEL free | 5962R9580901VRC, 5962R9580901VXC | QML Class V (space) |
| CMOS Non-Inverting Octal Buffer/Line Driver, Three-State | 200 | ELDRS free | SEL free | 5962R9573101VRC, 5962R9573101VXC | QML Class V (space) |
| CMOS Inverting Octal Buffer/Line Driver, Three-State | 200 | ELDRS free | SEL free | 5962R9577601VXC | QML Class V (space) |
| CMOS Non-Inverting Octal Buffer/Line Driver, Three-State | 200 | ELDRS free | SEL free | 5962R9575101V9A, 5962R9575101VXC | QML Class V (space) |
Tips for Using This Parametric Table:
- Hide Filters button in header: Collapse or expands filters
- Column sort buttons in header: Sort Column alphabetically / numerically descending or ascending
- Reset button in header: Reset all filters to the page default
- Full Screen button in header: Expand the table to full screen view (user must close out of full screen before they can interact with rest of page)
- Export button in header: Export the filtered results of the table to an Excel document
- Filter parts search bar in header: Type to filter table results by part number
- Hide column button in column headers: Select to hide columns in table
- AND / OR toggle switches in header: Toggles the logic of this particular filter to be “AND” or “OR” logic for filtering results
- Multiselect checkboxes at beginning of each row in table: Select these checkboxes to compare products against each other
- Document icon next to product name in row: View the featured document for this product
- Chip icon next to the right of the document icon in row: View the block diagram for this product
- Cart icon to the right of the chip icon: Indicates that samples are available for this product
Documentation
| Document title | Document type Type | Date Date | |
|---|---|---|---|
| PDF 338 KB | Application Note | ||
| PDF 224 KB | Application Note | ||
| PDF 467 KB | Brochure | ||
| PDF 4.85 MB | Brochure | ||
4 items
|
|||
