RH850/F1x, RH850/F1Kx 176-pin Piggyback Board of RH850 Evaluation Platform
The RH850/F1x 176-pin Piggyback Board supports all devices of the RH850/F1L and RH850/F1KM-S1 series in 176-pin package. It can be used standalone or in combination...
High-end In-vehicle Microcomputers for Body Applications
Jump to Page Section:
Overview
Description
The RH850/F1L is a product line in Renesas' RH850/F1x series of single-chip microcontrollers designed for automotive body applications. The embedded flash memory will range from 256KB to 2MB and packages will be covered from a small package 48-pin to 176-pin.
Features
- CPU: G3K core, Max. 80MHz
- Voltage: 3V to 5.5V
- Package: 48 to 176-pin LFQFP
- Memory: SRAM Max. 192KB, Program Flash Max. 2MB
- Timer: 32-bit Timer (ch) x 8, 16-bit Timer (ch) x 48, Watchdog Timer (ch) x 2, Timer for OS x 1ch
- PWM: PWM Output x 72, 3-phase PWM Output Function
- Analog function: 10-bit A/D Converter (ch) x 4, 12-bit A/D Converter (ch) x 91
- On-chip Oscillator Freq. (MHz): 8MHz, Low Speed: 240kHz
- Others: PLL, RTC, Power-On Reset, Low Voltage Detection
Applications
