This scalable SMARC 2.1 System on Module (SoM) with artificial intelligence (AI) solution is based on the powerful Renesas RZ/G2 microprocessor family and a full power and timing tree. It demonstrates a turn-key architecture for AI-enabled human machine interface (HMI) applications, such as smart industrial control terminals.

System Benefits​:

  • Linux operating system
  • 3D graphic acceleration engine
  • H.264 codecs (G2L and V2L)
  • DRP-AI for image AI application (V2L only)
  • Multiple core configurations for scalability
  • Single programmable clock generator on board
  • Extensive communications interface support
  • Robust power supply with hot plug/swap support

Target Applications:

  • Human machine interface (HMI)
  • Embedded vision applications
  • 3D animation displays
  • 4K video playback
  • Multimedia
  • AI IoT
HMI SoM with AI Accelerator
Legend for Renesas/Dialog System Diagrams


Related Products

Product Description Featured Document Ordering
Audio Codec
DA7212 Ultra-Low Power Stereo Codec with 650µW Always On Power Mode Datasheet Buy/Sample
Buck-Boost Controller
ISL81401A 40V Unidirectional 4-Switch Synchronous Buck-Boost Controller Datasheet Buy/Sample
Buck Regulator
ISL85413 Wide VIN 300mA Synchronous Buck Regulator Datasheet Buy/Sample
Clock Generator
5P35023 Programmable VersaClock® Clock Generator Datasheet Buy/Sample
Linear Regulator (LDO)
ISL80102 High Performance 2A Linear Regulator Datasheet Buy/Sample
ISL80505 High Performance 500mA LDO Datasheet Buy/Sample
AT25QL128A 128-Mbit SPI NOR Flash Memory with Dual and Quad I/O Support Datasheet Buy/Sample
RZ/G2L General-Purpose Microprocessor with Dual-Core Arm® Cortex®-A55 (1.2GHz) CPU, 3D Graphics and Video Codec Engine User's Manual Buy/Sample
RZ/G2LC General-Purpose Microprocessors with Dual-Core Arm Cortex-A55 (1.2 GHz) CPUs, with 3D Graphics User's Manual Buy/Sample
RZ/V2L General-Purpose Microprocessor Equipped With Renesas' Original AI-Dedicated Accelerator "DRP-AI", 1.2GHz Dual-Core Arm Cortex-A55 CPU, 3D Graphics, and Video Codec Engine User's Manual Buy/Sample
Power Management IC (PMIC)
RAA215300 High-Performance 9-Channel PMIC Supporting DDR Memory, with Built-In Charger and RTC Datasheet Buy/Sample
USB Power Delivery (PD) Controller
R9A02G011 USB PD Controller Datasheet Buy/Sample
Wi-Fi + Bluetooth® Low Energy Module
DA16600 Ultra-Low Power Wi-Fi + Bluetooth Low Energy Combo Modules for Battery-Powered IoT Devices Product Brief Contact Sales
