Renesas is the First-In, First-Out (FIFO) market leader with synchronous FIFO, asynchronous FIFO, queuing FIFO, and bidirectional FIFO products to help designers solve inter-chip communications protocol problems, such as rate matching, buffering and bus matching. Parallel FIFO structures allow the formulation of any word size while serial FIFO communications provide a rapid and simple link to other structures.

Renesas parallel FIFO product benefits include:

  • Superior off-the-shelf parallel FIFO solutions for high-performance applications, such as networking, wireless base stations, graphics, medical imaging, data acquisition, and industrial automation
  • Standard parallel FIFO products that help designers solve inter-chip communications protocol problems, such as rate matching, buffering and bus matching

Memory & Logic

Categories

Asynchronous FIFOs

Memory that allows data processing to continue before the transmission has finished

Queuing FIFOs

Devices the provide flexibility in how queues are configured

Synchronous FIFOs

Memory for buffering large amounts of data

Product Selection Table

    Processing table
    Part Number
    Core Voltage (V)
    Bus Width (bits)
    Density (Kb)
    Pkg. Code
    Interface
    I/O Type
    I/O Frequency (MHz)
    Organization
    Temp. Range
    Architecture
    Access Time (ns)
    105°C Max. Case Temp.
    7200
    256 x 9 AsyncFIFO, 5.0V    		 5 9 2 PEG28, PLG32 Asynchronous 5.0 V TTL 256 x 9 -40 to 85°C, 0 to 70°C Uni-directional 12, 15
    7201
    512 x 9 AsyncFIFO, 5.0V    		 5 9 4 PEG28, PLG32, PTG28 Asynchronous 5.0 V TTL 512 x 9 -40 to 85°C, 0 to 70°C Uni-directional 12, 15
    7202
    1K x 9 AsyncFIFO, 5.0V    		 5 9 9 PEG28, PLG32, PTG28 Asynchronous 5.0 V TTL 1K x 9 -40 to 85°C, 0 to 70°C Uni-directional 12, 15, 50
    7203
    2K x 9 AsyncFIFO, 5.0V    		 5 9 18 PLG32, PTG28 Asynchronous 5.0 V TTL 2K x 9 -40 to 85°C, 0 to 70°C Uni-directional 12, 15
    7204
    4K x 9 AsyncFIFO, 5.0V    		 5 9 36 PEG28, PLG32, PTG28 Asynchronous 5.0 V TTL 4K x 9 -40 to 85°C, 0 to 70°C Uni-directional 12, 15
    7205
    8K x 9 AsyncFIFO, 5.0V    		 5 9 72 PLG32, PTG28 Asynchronous 5.0 V TTL 8K x 9 -40 to 85°C, 0 to 70°C Uni-directional 12, 15
    7206
    16K x 9 AsyncFIFO, 5.0V    		 5 9 144 PLG32 Asynchronous 5.0 V TTL 16K x 9 0 to 70°C Uni-directional 15
    7207
    32K x 9 AsyncFIFO, 5.0V    		 5 9 288 PLG32 Asynchronous 5.0 V TTL 32K x 9 -40 to 85°C, 0 to 70°C Uni-directional 15, 20
    7208
    64K x 9 AsyncFIFO, 5.0V    		 5 9 512 PLG32 Asynchronous 5.0 V TTL 64K x 9 -40 to 85°C, 0 to 70°C Uni-directional 20, 25
    72125
    1K x 16 Parallel-to-Serial FIFO, 5.0V    		 5 16 16 PEG28, PTG28 Asynchronous 5.0 V TTL 1K x 16 0 to 70°C Parallel/Serial FIFOs 25
    72205
    256 x 18 SyncFIFO, 5.0V    		 5 18 4 PNG64 Synchronous 5.0 V TTL 100 256 x 18 0 to 70°C Uni-directional
    72215
    512 x 18 SyncFIFO, 5.0V    		 5 18 9 PNG64 Synchronous 5.0 V TTL 100, 66 512 x 18 -40 to 85°C, 0 to 70°C Uni-directional
    72225
    1K x 18 SyncFIFO, 5.0V    		 5 18 18 PNG64, PPG64 Synchronous 5.0 V TTL 100, 66 1K x 18 -40 to 85°C, 0 to 70°C Uni-directional
    72235
    2K x 18 SyncFIFO, 5.0V    		 5 18 36 PLG68, PNG64, PPG64 Synchronous 5.0 V TTL 100, 66 2K x 18 -40 to 85°C, 0 to 70°C Uni-directional
    72245
    4K x 18 SyncFIFO, 5.0V    		 5 18 64 PNG64 Synchronous 5.0 V TTL 100 4K x 18 0 to 70°C Uni-directional
    72255
    8K x 18 SuperSync FIFO, 5.0V    		 5 18 144 PNG64, PPG64 Synchronous 5.0 V TTL 100, 66 8K x 18 -40 to 85°C, 0 to 70°C Uni-directional
    72261
    16K x 9 SuperSync FIFO, 5.0V    		 5 9 144 PNG64, PPG64 Synchronous 5.0 V TTL 66, 100 16K x 9 -40 to 85°C, 0 to 70°C Uni-directional
    72265
    16K x 18 SuperSync FIFO, 5.0V    		 5 18 288 PNG64, PPG64 Synchronous 5.0 V TTL 100, 66 16K x 18 -40 to 85°C, 0 to 70°C Uni-directional
    72271
    32K x 9 SuperSync FIFO, 5.0V    		 5 9 288 PNG64 Synchronous 5.0 V TTL 100 32K x 9 0 to 70°C Uni-directional
    723622
    256 x 36 x 2 SyncBiFIFO, 5.0V    		 5 36 18 PNG120 Synchronous 5.0 V TTL 66 256 x 36 x 2 0 to 70°C Bi-directional
    723624
    256 x 36 x 2 SyncBiFIFO, 5.0V    		 5 36 18 PKG128 Synchronous 5.0 V TTL 66 256 x 36 x 2 0 to 70°C Bi-directional
    723632
    512 x 36 x 2 SyncBiFIFO, 5.0V    		 5 36 36 PNG120 Synchronous 5.0 V TTL 66 512 x 36 x 2 0 to 70°C Bi-directional
    723633
    512 x 36 SyncFIFO, 5.0V    		 5 36 9 PKG128 Synchronous 5.0 V TTL 83 512 x 36 0 to 70°C Uni-directional
    723642
    1K x 36 x 2 SyncBiFIFO, 5.0V    		 5 36 72 PNG120 Synchronous 5.0 V TTL 66 1K x 36 x 2 0 to 70°C Bi-directional
    723651
    2K x 36 SyncFIFO, 5.0V    		 5 36 72 PNG120 Synchronous 5.0 V TTL 50 2K x 36 -40 to 85°C Uni-directional
    72421
    64 x 9 SyncFIFO, 5.0V    		 5 9 1 PR32 Synchronous 5.0 V TTL 100 64 x 9 0 to 70°C Uni-directional
    7281
    512 x 9 DualAsync FIFO, 5.0V    		 5 9 4 PAG56 Asynchronous 5.0 V TTL 512 x 9 0 to 70°C Dual FIFO 12
    7282
    1K x 9 DualAsync FIFO, 5.0V    		 5 9 9 PAG56 Asynchronous 5.0 V TTL 1K x 9 0 to 70°C Dual FIFO 12
    7284
    4K x 9 DualAsync FIFO, 5.0V    		 5 9 36 PAG56 Asynchronous 5.0 V TTL 4K x 9 0 to 70°C Dual FIFO 12
    7285
    8K x 9 DualAsync FIFO, 5.0V    		 5 9 72 PAG56 Asynchronous 5.0 V TTL 8K x 9 -40 to 85°C Dual FIFO 15
    72T18105
    128K x 18 / 256K x 9 TeraSync FIFO, 2.5V    		 2.5 18 2048 BB240, BBG240 Synchronous 1.5 V HSTL, 1.8 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 128K x 18, 256K x 9 -40 to 85°C, 0 to 70°C Uni-directional
    72T18115
    256K x 18 / 512K x 9 TeraSync FIFO, 2.5V    		 2.5 18 4096 BB240 Synchronous 1.5 V HSTL, 1.8 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 256K x 18, 512K x 9 -40 to 85°C, 0 to 70°C Uni-directional
    72T18125
    512K x 18 / 1M x 9 TeraSync FIFO, 2.5V    		 2.5 18 9216 BB240, BBG240 Synchronous 1.5 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 1M x 9, 512K x 18 -40 to 85°C, 0 to 70°C Uni-directional
    72T36105
    64K x 36 TeraSync FIFO, 2.5V    		 2.5 36 2048 BB240 Synchronous 1.5 V HSTL, 1.8 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 64K x 36 -40 to 85°C, 0 to 70°C Uni-directional
    72T36115
    128K x 36 TeraSync FIFO, 2.5V    		 2.5 36 4096 BB240 Synchronous 1.5 V HSTL, 1.8 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 128K x 36 -40 to 85°C, 0 to 70°C Uni-directional
    72T36125
    256K x 36 TeraSync FIFO, 2.5V    		 2.5 36 9216 BB240, BBG240 Synchronous 1.5 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 256K x 36 -40 to 85°C, 0 to 70°C Uni-directional
    72T72105
    64K x 72 TeraSync FIFO, 2.5V    		 2.5 72 4096 BB324, BBG324 Synchronous 1.5 V HSTL, 1.8 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 64K x 72 -40 to 85°C, 0 to 70°C Uni-directional
    72T72115
    128K x 72 TeraSync FIFO, 2.5V    		 2.5 72 9216 BB324, BBG324 Synchronous 1.5 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 128K x 72 -40 to 85°C, 0 to 70°C Uni-directional
    72T7285
    16K x 72 TeraSync FIFO, 2.5V    		 2.5 72 1024 BB324, BBG324 Synchronous 1.5 V HSTL, 1.8 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 16K x 72 0 to 70°C Uni-directional
    72T7295
    32K x 72 TeraSync FIFO, 2.5V    		 2.5 72 2048 BB324, BBG324 Synchronous 1.5 V HSTL, 2.5 V LVTTL, 3.3 V LVTTL 100, 225, 200, 150 32K x 72 0 to 70°C Uni-directional
    72V01
    512 x 9 AsyncFIFO, 3.3V    		 3.3 9 4 PLG32 Asynchronous 3.3 V LVTTL 512 x 9 -40 to 85°C, 0 to 70°C Uni-directional 15, 25
    72V02
    1K x 9 AsyncFIFO, 3.3V    		 3.3 9 9 PLG32 Asynchronous 3.3 V LVTTL 1K x 9 -40 to 85°C, 0 to 70°C Uni-directional 15, 25
    72V03
    2K x 9 AsyncFIFO, 3.3V    		 3.3 9 18 PLG32 Asynchronous 3.3 V LVTTL 2K x 9 -40 to 85°C, 0 to 70°C Uni-directional 15, 25
    72V04
    4K x 9 AsyncFIFO, 3.3V    		 3.3 9 36 PLG32 Asynchronous 3.3 V LVTTL 4K x 9 -40 to 85°C, 0 to 70°C Uni-directional 15, 25
    72V05
    8K x 9 AsyncFIFO, 3.3V    		 3.3 9 72 PLG32 Asynchronous 3.3 V LVTTL 8K x 9 -40 to 85°C, 0 to 70°C Uni-directional 15, 25
    72V06
    16K x 9 AsyncFIFO, 3.3V    		 3.3 9 144 PLG32 Asynchronous 3.3 V LVTTL 16K x 9 -40 to 85°C, 0 to 70°C Uni-directional 15, 25
    72V205
    256 x 18 SyncFIFO, 3.3V    		 3.3 18 4 PNG64, PPG64 Synchronous 3.3 V LVTTL 100, 66 256 x 18 -40 to 85°C, 0 to 70°C Uni-directional
    72V2101
    256K x 9 SuperSync FIFO, 3.3V    		 3.3 9 2048 PNG64 Synchronous 3.3 V LVTTL 100 256K x 9 0 to 70°C Uni-directional
    72V2103
    128K x 18 / 256K x 9 SuperSync II FIFO, 3.3V    		 3.3 18 2048 BC100, BCG100, PNG80 Synchronous 3.3 V LVTTL 66, 166, 133 128K x 18, 256K x 9 -40 to 85°C, 0 to 70°C Uni-directional
    72V2105
    256K x 18 SuperSync FIFO, 3.3V    		 3.3 18 4096 PNG64 Synchronous 3.3 V LVTTL 100, 66 256K x 18 -40 to 85°C, 0 to 70°C Uni-directional
    Parametric Table tips

    Tips for Using This Parametric Table:

    • Hide Filters button in header: Collapse or expands filters
    • Column sort buttons in header: Sort Column alphabetically / numerically descending or ascending
    • Reset button in header: Reset all filters to the page default
    • Full Screen button in header: Expand the table to full screen view (user must close out of full screen before they can interact with rest of page)
    • Export button in header: Export the filtered results of the table to an Excel document
    • Filter parts search bar in header: Type to filter table results by part number
    • Hide column button in column headers: Select to hide columns in table
    • AND / OR toggle switches in header: Toggles the logic of this particular filter to be “AND” or “OR” logic for filtering results
    • Multiselect checkboxes at beginning of each row in table: Select these checkboxes to compare products against each other
    • Document icon next to product name in row: View the featured document for this product
    • Chip icon next to the right of the document icon in row: View the block diagram for this product
    • Cart icon to the right of the chip icon: Indicates that samples are available for this product
