SLG59H1009V Evaluation Board
The SLG59H1009V-EVB board evaluates the SLG59H1009V High Voltage GreenFET, Load Switch.
For details on how to use the evaluation board, please refer to the evaluation...
Featured Documents:
Overview
Description
The SLG59H1009V is a high-performance, self-powered 13.1mΩ NMOS load switch designed for all 4.5V to 22V power rails up to 4A. Using a proprietary MOSFET design, the SLG59H1009V achieves a stable 13.1mΩ RDSON across a wide input voltage range. Combining novel FET design and copper pillar interconnects, the SLG59H1009V package also exhibits a low thermal resistance for high-current operation. Designed to operate over a -40 °C to 85 °C temperature range, the SLG59H1009V is available in a low thermal resistance, RoHS‑compliant, 1.6mm x 3.0mm STQFN package.
Features
- Optimized for Telecommunications Equipment, High-performance Enterprise Computing, Motor Drives
- 13.1mΩ RDSON
- Maximum Continuous Current: 4A
- Wide Operating Supply Voltage: 4.5V to 22V
- Automatic nFET SOA Protection
- Capacitor-adjustable Inrush Current Control
- Two-stage Current Limit Protection:
- Resistor-adjustable Active Current Limit
- Fixed 0.5A Short-circuit Current Limit
- ON-OFF Control: Active HIGH
- UL2367 Certified - File Number E468659
Comparison
Applications
- Power-Rail Switching
- Multifunction Printers
- Large-format Copiers
- Telecommunications Equipment
- High-performance Computing 5V, 9V, 12V, and 20V Point-of-Load Power Distribution
- Motor Drives
