R8A66597FP High Speed USB Embedded Host Controller Evaluation Board
The R0K866597D020BR eval board is equipped with a R8A66597FP high speed USB embedded host controller. This Eval board also can be utilized as a USB peripheral function....
RX62N Group microcontrollers have 100 MHz high-speed operation and enhanced communications functions. They have built-in Ethernet, CAN, and two circuits of USB 2.0 host controller. A multifunction timer (MTU2, 2 units), 10-bit or 12-bit A/D converter, DMA controller, and other peripheral functions are incorporated on a single chip. Up to 512 KB flash memory and 96 KB RAM are built in, as well as 32 KB of flash memory for data storage. Packages from 85 to 176 pins are available.
