Overview

IDTs ADC1410S125F2 demoboard is suitable for dynamic performance evaluations from low to high IF configuration with LVDS DDR output variants. A data-acquisition board can be used during design and prototype to analyze ADC performance.

ADC1410S125F2 - Evaluation Board
ADC1410S125F2 - Evaluation Board
  • LVDS/DDR outputs
  • Single power supply (on-board regulators)
  • SMA connector for clock and analog input signals

Documentation

Title
Type Date
Demo Board Software ADC_1_r04
ZIP 2.33 MB 		Manual - Software
1 item

Product Options

    Processing table
    EPC
    Pkg. Type
    Lead Count (#)
    Temp. Grade
    Pb (Lead) Free
    Buy / Sample
    Part Number
    ADC1410S125F2-DB
    block_flippedObsolete
    		 BD0 BOARD 0 I No
