16(+1) Channel T1/J1/E1 Short Haul LIU
Jump to Page Section:
Overview
Description
16 (+1)-Channel T1/E1/J1 Short Haul Line Interface Unit. This device has an adaptive equalizer integrated, performs clock.data recovery, line decoding/encoding and has one jitter attenuator. Optimized to be used in LAN, WAN, Routers, Wireless Base Stations, Gateways etc.
Features
Integrates 16+1 channels T1/E1/J1 short haul line interface units for 100 | T1, 120 | E1, 110 | J1 twisted pair cable and 75 | E1 coaxial cable applications
Per-channel configurable Line Interface options
Per-channel system and diagnostic functions
Hitless Protection Switching (HPS) without external Relays
Integrated clock synthesizer
Supports Serial microprocessor interface and Parallel Intel / Motorola Non-Multiplexed /Multiplexed microprocessor interface
3.3 V and 1.8 V power supply
Package: 416-pin PBGA (27 mm X 27 mm)
Design & Development
Software & Tools
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Product Options
Processing table
| PBGA | 416 | Yes | Tray | Get Samples, |
