Package Information
| Lead Count (#) | 3 |
| Pkg. Code | PAB |
| Pitch (mm) | |
| Pkg. Type | SOT23 |
| Pkg. Dimensions (mm) | 2.92 x 1.30 x 0.00 |
Environmental & Export Classifications
| Pb (Lead) Free | No |
| ECCN (US) | EAR99 |
| Moisture Sensitivity Level (MSL) | |
| HTS (US) |
Product Attributes
| Lead Count (#) | 3 |
| Carrier Type | Reel |
| Pb (Lead) Free | No |
| Temp. Range | -40 to +85°C |
| Hysteresis (ppm) | 40 |
| IS (mA) | 0.025 |
| ISINK (Max) (mA) | 10 |
| ISOURCE (Max) (mA) | 10 |
| Initial Accuracy (% Vout) (% Vout) | 0.48 |
| Initial Accuracy (mV (±)) (mV (±)) | 10 |
| LTD Stability (ppm) | 50 |
| Length (mm) | 2.9 |
| Low Frequency Noise (µVPP) | 30 |
| MOQ | 2000 |
| Output Noise (Typical) | 30 µVPP |
| Parametric Category | Voltage References |
| Pitch (mm) | 0 |
| Pkg. Dimensions (mm) | 2.9 x 1.3 x 0.00 |
| Pkg. Type | SOT23 |
| Qualification Level | Standard |
| Supply Voltage Vs Range | 2.7 to 5.5 |
| Technology | Floating Gate Array |
| Temperature Coefficient (ppm/°C) | 30 |
| Thickness (mm) | 0 |
| VOUT (V) | 2.048 |
| VS (Max) (V) | 5.5 V |
| VS (Min) (V) | 2.7 V |
| Width (mm) | 1.3 |
Description
Support is limited to customers who have already adopted these products.
The ISL21070 voltage references are analog voltage references featuring low supply voltage operation at ultra-low 25µA max operating current. Additionally, the ISL21070 family features guaranteed initial accuracy as low as ±0. 2% and 30ppm/°C temperature coefficient. These references are ideal for general purpose applications for performance at lower cost. The ISL21070 is provided in an industry standard 3 Ld SOT-23 pinout. The ISL21070 offers output voltages that can be used as precision voltage sources for control loops, standby voltages for low power states for DSP, FPGA, Data path Controllers, Microcontrollers and other core voltages: 0. 600V, 2. 048V, and 2. 5V.
