HS4001 Relative Humidity and Temperature Sensor Evaluation Kit
The HS4000-EVK Evaluation Kit is used to assess the HS4001 High-Performance Relative Humidity and Temperature Sensor, with Digital I2C output. The hardware allows users...
Relative Humidity and Temperature Sensor with Hydrophobic Membrane, Digital Output, ±1.5% RH
Jump to Page Section:
Overview
Description
The HS4011 is a highly accurate, ultra-low power, fully calibrated relative humidity and temperature sensor with a hydrophobic membrane. The MEMS sensor features a proprietary sensor-level protection ensuring high reliability and long-term stability. The HS4011 is fully calibrated and temperature compensated with an I2C digital output.
Features
- Humidity range: 0% to 100%RH
- RH accuracy: ±1.5%RH, typical
- Hydrophobic membrane, IP67 rated
- I2C digital output
- 14-bit resolution
- Fast RH response time: 4 seconds, typical
- Temperature sensor accuracy: ±0.2°C, typical (-10°C to +80°C)
- Low current consumption: 0.3µA average (8-bit resolution, 3.3V supply), 0.62µA average (14-bit resolution, 3.3V supply), one RH and temperature measurement per second
- Excellent stability against aging
Applications
Documentation
| Type | Date | |
|---|---|---|
| PDF 825 KB | Datasheet | |
| PDF 131 KB | Application Note | |
| PDF 368 KB | Product Change Notice | |
| PDF 1.73 MB | Certificate | |
| PDF 600 KB 日本語 | Overview | |
5 items
|
||
Design & Development
Boards & Kits
Boards & Kits
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Processing table
| LGA | 8 | -40 to 125°C | Yes | Cut Tape | Get Samples, |
