Overview

Description

The Renesas SH C Compiler is an optimising ANSI C and ANSI C++ compiler for the SuperH embedded RISC microprocessor family. The SH C package includes a compiler, assembler and linker is supplied as part of the High-performance Embedded Workshop IDE.

In addition to full ANSI C support, the compiler provides #pragma language extensions and command-line switches to support target specific features and extended compiler functionality.

The SH C compiler has powerful and reliable code generation facilities for SH targets. A variety of optimisation features allow you to generate highly optimised PROMable code. In particular, code can be optimised for size or speed to match the requirements of the particular application being developed...

Features

  • High-performance Embedded Workshop
  • Tool chain
  • Simulator
  • Call Walker
  • MapViewer
  • Learn More
