SLG59H1017V Evaluation Board
The SLG59H1017V-EVB board evaluates the SLG59H1017V High Voltage GreenFET, Load Switch.
For details on how to use the evaluation board, please refer to the evaluation...
Featured Documents:
Overview
Description
The SLG59H1017V is a high‑performance 13.3mΩ NMOS load switch designed to control 12V or 24V power rails up to 4A. Using a proprietary MOSFET design, the SLG59H1017V achieves a stable 13.3mΩ RDSON across a wide input voltage range. Combining novel FET design and copper pillar interconnects, the SLG59H1017V package also exhibits a low thermal resistance for high‑current operation. Designed to operate over a -40 °C to 85 °C temperature range, the SLG59H1017V is available in a low thermal resistance, RoHS‑compliant, 1.6mm x 3.0mm STQFN package.
Features
- Low RDSON: 13.3mΩ
- Maximum Continuous Current: 4A
- Wide Operating Supply Voltage: 12V or 24V
- Automatic 10W nFET SOA Protection
- Capacitor-adjustable Inrush Current Control
- Two stage Current Limit Protection:
- Resistor-adjustable Active Current Limit
- Fixed 0.5A Short-circuit Current Limit
- Fast VOUT Discharge
- ON-OFF Control: Active HIGH
- Pb-free/RoHS-Compliant Package
Comparison
Applications
- Power-Rail Switching
- Multifunction Printers
- Large-format Copiers
- Telecommunications Equipment
- High-performance Computing
- 12V and 24V Point‑of‑Load Power Distribution
- Motor Drives
