F1280 Dual Variable Gain Amplifier Evaluation Kit
The F1280EVK is a fully populated evaluation board that allows the customer to evaluate the F1280 dual VVA+VGA with integrated RMS detectors. The F1280 VGA gain ranges...
The F1280 is a highly integrated 0.001MHz to 1200MHz dual VVA+VGA with integrated RMS detectors. The two independently controlled VVA+VGAs each provide 24dB of gain range with four different selectable gain ranges. The VGA gain ranges and switchable VGA2 inputs are controlled through an SPI interface with a 10MHz maximum clock operating frequency.
|Datasheet||PDF 1.19 MB|
|Guide||PDF 2.24 MB|
