Memory & Logic

Renesas offers a family of 5V bus switches that provide high-speed switching without adding propagation delay or generating additional ground bounce noise. These are ideal for bidirectional interfaces between mixed-supply busses, and in applications that require isolation and protection.

Product Selection Table

    Processing table
    Function
    Pkg. Code
    Temp. Range
    Bus Width (bits)
    Core Voltage (V)
    On Resistance (Ω)
    Speed Grade
    105°C Max. Case Temp.
    Part Number
    QS3125
    High-Speed CMOS Quadruple Bus Switch with IndiviDual Active Low Enables    		 Bus Switch PCG16 -40 to 85°C 4 5 5 Standard
    QS3244
    High-Speed CMOS QuickSwitch 8-Bit Bus Switch    		 244 Switch PCG20 -40 to 85°C 8 5 5 Standard
    QS3245
    High-Speed CMOS QuickSwitch 8-Bit Bus Switch    		 245 Switch PCG20, PSG20 -40 to 85°C 8 5 5 Standard
    QS3251
    High-Speed CMOS QuickSwitch 8:1 Mux/Demux    		 8:1 Mux/Demux PCG16 -40 to 85°C 8 5 5 Standard
    QS3253
    High-Speed CMOS QuickSwitch Dual 4:1 Mux/Demux    		 2x4:1 Mux/Demux PCG16 -40 to 85°C 8 5 5 Standard
    QS3257
    High-Speed CMOS QuickSwitch Quad 2:1 Mux/Demux    		 4x2:1 Mux/Demux PCG16 -40 to 85°C 8 5 5 Standard
    QS3383
    10-Bit Bus Exchange Switch    		 Bus Switch/Exchange PCG24 -40 to 85°C 10 5 5 Standard
    QS3384
    High-Speed CMOS 10-Bit Bus Switch    		 Bus Switch PCG24 -40 to 85°C 10 5 5 Standard
    QS3861
    High-Speed CMOS 10-Bit Bus Switch with Flow-Thru Pinout    		 Bus Switch (Flow-through) PCG24, PGG24 -40 to 85°C 10 5 5 Standard
    Parametric Table tips

    Tips for Using This Parametric Table:

    • Hide Filters button in header: Collapse or expands filters
    • Column sort buttons in header: Sort Column alphabetically / numerically descending or ascending
    • Reset button in header: Reset all filters to the page default
    • Full Screen button in header: Expand the table to full screen view (user must close out of full screen before they can interact with rest of page)
    • Export button in header: Export the filtered results of the table to an Excel document
    • Filter parts search bar in header: Type to filter table results by part number
    • Hide column button in column headers: Select to hide columns in table
    • AND / OR toggle switches in header: Toggles the logic of this particular filter to be “AND” or “OR” logic for filtering results
    • Multiselect checkboxes at beginning of each row in table: Select these checkboxes to compare products against each other
    • Document icon next to product name in row: View the featured document for this product
    • Chip icon next to the right of the document icon in row: View the block diagram for this product
    • Cart icon to the right of the chip icon: Indicates that samples are available for this product
