Renesas' radiation hardened NAND gates provide the system designer with direct implementation of the NAND function and supplement the existing family of CMOS gates.
Product Selection Table
Processing table
High Dose Rate (HDR) (krad (Si)) |
Low Dose Rate (LDR) (krad (Si)) |
DSEE (SEL, SEB, etc.) (MeV*cm2/mg) |
DLA SMD |
Qualification Level |
|
|---|---|---|---|---|---|
| Part Number | |||||
| CMOS Quad 2-Input NAND Gate with Open Drain | 300 | ELDRS free | SEL free | 5962F9670301V9A, 5962F9670301VCC, 5962F9670301VXC | QML Class V (space) |
| CMOS Dual 2-Input NAND Buffer/Driver | 100 | ELDRS free | 75 | 5962R9664401VXC | QML Class V (space) |
| CMOS NAND Gate | 100 | ELDRS free | 75 | 5962R9662103V9A, 5962R9662103VCC, 5962R9662103VXC | QML Class V (space) |
| Quad 2-Input NAND Gate | 200 | 5962R9572401V9A, 5962R9572401VCC, 5962R9572401VXC | QML Class V (space) | ||
| CMOS Dual 4-Input NAND Gate | 200 | ELDRS free | SEL free | 5962R9573301VXC | QML Class V (space) |
