ISL28236SOICEVAL1Z

Obsolete

5MHz, Dual Precision Rail-to-Rail Input-Output (RRIO) Op Amp Evaluation Board

ISL282x6EVAL1Z User Guide

Overview

The ISL28236SOICEVAL1Z evaluation board is a design platform containing all the circuitry needed to characterize critical performance parameters of the ISL28236 operational amplifier in the SOIC-8 package, using a variety of user-defined test circuits.

The ISL28236 high-speed operational amplifier features low-power consumption, has rail-to-rail output drive capability, and is designed to operate with a single lithium cell or two NiCd batteries.

ISL28236SOICEVAL1Z Op Amp Eval Board
ISL28236SOICEVAL1Z Op Amp Eval Board
  • Single-supply operation: +2.4VDC to +5.5VDC
  • Dual-supply operation: ±1.2VDC to ±2.75V
  • Configured for a dual op amp connected for differential input with a closed-loop gain of 10
  • Includes a single external reference voltage (VREF) pin and provisions for a user-selectable voltage divider (filter included)

Documentation

Featured Documentation
Type Title Date
Manual - Development Tools
ISL282x6EVAL1Z User Guide
PDF 483 KB
1 item

Design & Development

Models
Type Title Date
Model - SPICE
ISL28136, ISL28236 Macromodel
TXT 5 KB
1 item
