Overview

The ISL54222A is a single supply dual 2:1 multiplexer that can operate from a single 1.8V to 3.3V supply. It contains two Single Pole/Double Throw (SPDT) switches configured as a DPDT. The part was designed for switching or routing of USB High-Speed signals and/or USB Full-Speed signals in portable battery-powered products. The 4.4Ω switches can swing rail-to-rail and were specifically designed to pass USB Full-Speed data signals that range from 0V to 3.3V and USB High-Speed data signals that range from 0V to 400mV with a single supply as low as 1.8V. They have high bandwidth and low capacitance to pass USB High-Speed data signals with minimal distortion. The digital logic inputs are 1.8V logic compatible when operated with a 1.8V to 3.3V supply. The ISL54222A has an output enable pin to open all the switches and put the part in a low power state. The ISL54222A is available in 10 Ld 1.8mm x 1.4mm µTQFN, 10 Ld 2.1mm x 1.6mm µTQFN, 10 Ld TDFN and 10 Ld MSOP packages. It operates over a temperature range of -40 °C to +85 °C.

ISL54222A Functional Diagram
ISL54222A Functional Diagram
  • High-speed (480Mbps) and full-speed (12Mbps) signaling capability per USB 2.0
  • 1.8V logic compatible
  • Low power all off state
  • Power OFF protection
  • D-/D+ pins overvoltage tolerant to 5.5V
  • -3dB frequency: 780MHz
  • Low ON capacitance @ 240MHz: 4.2pF
  • Low ON-resistance @ VDD = 3V: 4.4Ω
  • Low ON-resistance @ VDD = 1.8V: 5.7Ω
  • Single supply operation (VDD): 1.8V to 3.3V
  • Available in µTQFN, TDFN, MSOP packages
  • Pb-free (RoHS compliant)
  • Compliant with USB 2.0 short circuit and overvoltage requirements without additional external components
  • HBM ESD performance I/O to GND: >12kV

Applications

  • MP3 and other personal media players
  • Cellular/Mobile phones
  • PDAs
  • Digital cameras and camcorders
  • USB switching

Documentation

Design & Development

Boards & Kits

ISL54222AIRUEVAL1Z High-Speed Multiplexer Eval Board

ISL54222AIRUEVAL1Z

Evaluation
Order Now

High-Speed USB 2.0 (480Mbps) Multiplexer Evaluation Board

The ISL54222AIRUEVAL1Z evaluation board is designed to provide a quick and easy method for evaluating the ISL54222A high-speed USB 2.0 multiplexer.

The evaluation...

Featured Documents:
ISL54222AIRUEVAL1Z User Guide

ECAD Models

Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.

Explore ECAD Models

Product Options

    Processing table
    Part Number
    Pkg. Type
    Carrier Type
    MOQ
    Buy / Sample
    ISL54222AIRTZ
    play_circleActive
    memory
    spa
    view_in_ar
    Samples Available
    		 TDFN Tube 4000 Get Samples,
    ISL54222AIRTZ-T
    play_circleActive
    memory
    spa
    view_in_ar
    Samples Available
    		 TDFN Reel 6000 Get Samples,
    ISL54222AIRU1Z-T
    play_circleActive
    memory
    spa
    view_in_ar
    Samples Available
    		 uTQFN Reel 3000 Get Samples,
    ISL54222AIRUZ-T
    play_circleActive
    memory
    spa
    view_in_ar
    Samples Available
    		 uTQFN Reel 3000 Get Samples,
    ISL54222AIUZ
    play_circleActive
    memory
    spa
    view_in_ar
    Samples Available
    		 MSOP Tube 4000 Get Samples,
    ISL54222AIUZ-T
    play_circleActive
    memory
    spa
    view_in_ar
    Samples Available
    		 MSOP Reel 2500 Get Samples,
