Overview
Description
The ISL28213 is a dual channel general purpose micropower, rail-to-rail input and output (RRIO) operational amplifier with a supply voltage range of 1.8V to 5.5V. Key features are a low supply current of 130µA maximum per channel at room temperature, a low bias current and a wide input voltage range, which enables the ISL28213 device to be an excellent general purpose operational amplifier for a wide range of applications. The ISL28213 is available in the MSOP8, SOIC8 and SOT23-8 packages. And, this device operates across the extended temperature range of -40 °C to +125 °C.
Features
- Low current consumption: 130µA
- Wide supply range: 1.8V to 5.5V
- Gain bandwidth product: 2MHz
- Input bias current: 20pA, Max.
- Operating temperature range: -40 °C to +125 °C
- Packages: MSOP8, SOIC8, SOT23-8
Comparison
Applications
Design & Development
Boards & Kits
Evaluation
ISL28213MSOPEVAL2Z
Active
Dual General-Purpose Micropower, RRIO Op Amp in MSOP Packages Evaluation Board
The ISL28213MSOPEVAL2Z evaluation board is a design platform containing all the circuitry needed to characterize critical performance parameters of the ISL28213 operational amplifier, using a variety of user-defined test circuits.
The ISL28213MSOPEVAL2Z is designed to enable the ISL28213 IC to...
Recommended Documents:
Evaluation
ISL28213SOICEVAL2Z
Active
Dual General-Purpose Micropower, RRIO Op Amps in SOIC Packages Evaluation Board
The ISL28213SOICEVAL2Z evaluation board is a design platform containing all the circuitry needed to characterize critical performance parameters of the ISL28213 operational amplifier, using a variety of user-defined test circuits.
The ISL28213SOICEVAL2Z is designed to enable the ISL28213 IC to...
Recommended Documents:
Evaluation
ISL28214MSOPEVAL2Z
Active
Dual General-Purpose Micropower, RRIO Op Amp in MSOP Packages Evaluation Board
The ISL28214MSOPEVAL2Z evaluation board is a design platform containing all the circuitry needed to characterize critical performance parameters of the ISL28214 operational amplifier, using a variety of user-defined test circuits.
The ISL28214MSOPEVAL2Z is designed to enable the ISL28214 IC to...
Recommended Documents:
Evaluation
ISL28214SOICEVAL2Z
Active
Dual General-Purpose Micropower, RRIO Op Amps in SOIC Packages Evaluation Board
The ISL28214SOICEVAL2Z evaluation board is a design platform containing all the circuitry needed to characterize critical performance parameters of the ISL28214 operational amplifier, using a variety of user-defined test circuits.
The ISL28214SOICEVAL2Z is designed to enable the ISL28214 IC to...
Recommended Documents:
Development
AS104-PDTURBOPOCZ
Active
USB PD with Turbo Boost Development Kit
The USB PD with Turbo Boost Development Kit is used for developing applications with Universal Serial Bus Power Delivery (USB PD). The kit utilizes Renesas' R9A02G011 USB PD 3.0 controller, ISL81401 bidirectional buck-boost voltage regulator, and ISL9238 battery charger controller. The input...
Test this Board Remotely
Available on Lab on the Cloud, use our PC-based GUI to instantly start configuring and testing designs in our virtual lab, no physical board needed.
Evaluation
CN032-GATEWAYREFZ
Active
RZ/N2L Remote I/O Solution Kit
The RZ/N2L Remote I/O Solution Kit is a development kit for evaluating remote I/O applications using the RZ/N2L Gateway Solution Board which is equipped with digital IO interface with photocoupler isolation and analog input and supports industrial network communications such as EtherCAT and...
Recommended Documents:
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on the CAD Model links in the Product Options table. If a symbol or model isn't available, it can be requested directly from SamacSys.
