SLG59H1005V Evaluation Board
The SLG59H1005V-EVB board evaluates the SLG59H1005V High Voltage GreenFET, Load Switch.
For details on how to use the evaluation board, please refer to the evaluation...
Featured Documents:
Overview
Description
The SLG59H1005V is a high‑performance, self‑powered 50mΩ NMOS load switch with back-to-back reverse‑current blocking designed for all 4.5V to 22V power rails up to 3A. Using a proprietary MOSFET design, the SLG59H1005V achieves a stable 50mΩ RDSON across a wide input voltage range. In combining novel FET design and copper pillar interconnects, the SLG59H1005V package also exhibits a low thermal resistance for high‑current operation. Designed to operate over a -40 °C to 85 °C range, the SLG59H1005V is available in a low thermal resistance, RoHS‑compliant, 1.6mm x 3.0mm STQFN package.
Features
- Optimized for Telecommunications Equipment, High‑performance Enterprise Computing, Motor Drives
- 50mΩ RDSON
- Maximum Continuous Current: 3A
- Wide Operating Supply Voltage: 4.5V to 22V
- Back-to-Back FET Reverse-current Blocking, when OFF
- Automatic nFET SOA Protection
- Four-level, Pin-selectable VIN Overvoltage Lockout
- Capacitor-adjustable Inrush Current Control
- Two-stage Current Limit Protection:
- Resistor-adjustable Active Current Limit
- Fixed 0.5A Short-circuit Current Limit
- ON-OFF Control: Active HIGH
Comparison
Applications
- Power-Rail Switching
- Multifunction Printers
- Large-format Copiers
- Telecommunications Equipment
- High-performance Computing 4.5V and 22V Point‑of‑Load Power Distribution
- Motor Drives
