R-Car S4 Starter Kit
Jump to Page Section:
Overview
Description
The R-Car S4 Starter Kit is a low-cost, readily available development board for building software using the Renesas R-Car S4 system on chip (SoC). The SoC delivers high computing performance and an array of communication features for both cloud communication and safe vehicle control. The new starter kit is a less-expensive and readily-available option compared to the existing R-Car S4 Reference Board, which provides a full-scale development environment including an evaluation board and software. Engineers can take advantage of the new kit to easily start their initial evaluation of car servers, connected gateways, connectivity modules and more, for rapid application development.
Features
- Simplifies the process of establishing open-source automotive Linux environments.
- The R-Car starter kits are designed to simplify the task of setting up automotive Linux environments for engineers who are new to the development of automotive software, and are competitively priced so that each developer can be provided with their own kit.
- Eight 1.2 GHz Cortex A55 cores, one 1.0 GHz Cortex® R52 dual core (lock-step) and two 400 MHz RH850 G4MH dual cores (lock-step) deliver up to 27 kDMIPS application performance plus greater than 5.3 kDMIPS real-time performance.
- Ethernet TSN x 2
- CAN FD x2, LIN x 1
- 128GiB UFS
- 64MiB Quad SPI flash memory
Applications
Applications
- Gateway and domain control
Documentation
= Featured Documentation
Log in required to subscribe
|
|
|
|
|---|---|---|
| Type | Title | Date |
| Manual - Development Tools | PDF 4.50 MB | |
| Manual - Hardware | PDF 467 KB | |
2 items
|
||
Design & Development
Software & Tools
Software & Tools
| Software title
|
Software type
|
Company
|
|---|---|---|
| R-Car S4 SDK for gateway R-Car S4 SDK is SW platform based on Linux and also common for R-Car S4 Spider board. Please download R-Car S4 SDK from R-Car S4 product page which this link guides to move to. NDA will be displayed before download of R-Car S4 SDK and acceptance of it is required for download.
|
Software Package | Renesas |
| Yocto Linux BSP (elinux.org) This link goes to the Linux BSP page for R-Car S4 Starter Kit on eLinux wiki. It explains how to build the Linux BSP included in the R-Car S4 SDK.
|
Software Package | Renesas |
| Hypervisor Xen BSP (elinux.org) This link goes to the Xen BSP page for R-Car S4 Starter Kit on eLinux wiki. It explains how to build the Xen BSP included in the R-Car S4 SDK.
|
Software Package | Renesas |
| R-Car S4 Whitebox SDK - Integrated Development Platform for Connected Services and Gateway Application The R-Car S4 Whitebox SDK is an integrated development platform that accelerates the development of connected services applications. All software is provided as an all-in-one package under a Free of Charge (FoC) license.
|
Software Package | Renesas |
4 items
|
||
Related Boards & Kits
Boards & Kits
Videos & Training
How to Use Q/A Forum
Video List
News & Blog Posts
| Blog Post | Jul 22, 2023 | ||
| News | Jul 11, 2023 |
Specifications
| Class | Function |
|---|---|
| CPU | Eight 1.2 GHz Cortex A55 cores, one 1.0 GHz Cortex® R52 dual core (lock-step) and two 400 MHz RH850 G4MH dual cores (lock-step) |
| Memory | LPDDR4X (4GByte) QSPI (64MByte) UFS memory (128GByte) uSD-card socket x1 |
| Connectors | CN1 RJ45 for ETNB0 (100BASE-TX) CN2 SoC Debug 1 CN3 Fan CN5 Micro-SD card slot CN7 LIN, 1 channel CN8 Power input, 5V/4A CN9 CAN-FD, 2 channels CN10 SoC Debug 0 CN13 Micro-USB-B for dual-serial and configuration CN18 Expansion connector (bottom) CN21 Expansion connector (bottom) CN23 Trace aux signals CN24 Expansion connector (bottom) CN30 PCIe root complex/downstream channel 0, 2 lanes CN31 PCIe endpoint/upstream channel 1, 2 lanes CN43 Remote (Power enable, Reset) IC101 RJ45 for TSN0 (1000BASE-T) IC104 RJ45 for TSN1 (1000BASE-T) |
| Board Specifications | Power input, 5V/4A Dimensions 110 x 127 mm |
