RTD60 Series Silicon Based Thermopile Detector
ページセクションへ移動：
Back to top
ECADモデルを調べる
概要
Description
The RTD60 (single-channel) and RTD60D (dual-channel) Silicon Based Thermopile Detectors provide low cost high output sensing solutions in a TO-5 package. Time constant of 25ms with Nitrogen encapsulation gas. Delivers a very low Temperature Coefficient of Responsivity of -0.04%/C. These detectors have a very short thermal shock response to ambient temperature change.
特長
- Fast response
- Best-in-class signal-to-noise ratio
- High operating temperature
- System design support with cost-optimized BoM and FW / algorithm support
- Single and dual channel detectors
アプリケーション
アプリケーション
- Non-contact temperature
- Fire suppression
- Horizon sensor
- Gas analysis
設計・開発
ボード＆キット
ボード＆キット
RTD120D Thermopile Gas Detector CO2 Evaluation Kit
The RTD120D Thermopile Gas Detector CO2 evaluation kit (EVK) creates an easy way to evaluate the RTD120D Dual Channel Thermopile Gas Detector in a CO2 detector...
