Relative Humidity and Temperature Sensor, Digital Output, ±1.5% RH
Jump to Page Section:
Overview
Description
The HS4001 is a highly accurate, ultra-low power, fully calibrated relative humidity and temperature sensor. The MEMS sensor features a proprietary sensor-level protection ensuring high reliability and long-term stability. The HS4001 is fully calibrated and temperature compensated with an I2C digital output.
Features
- Humidity range: 0% to 100%RH
- RH accuracy: ±1.5%RH, typical
- I2C digital output
- 14-bit resolution
- Fast RH response time: 4 seconds, typical
- Temperature sensor accuracy: ±0.2°C, typical (-10°C to +80°C)
- Low current consumption: 0.3µA average (8-bit resolution, 3.3V supply), 0.62µA average (14-bit resolution, 3.3V supply), one RH and temperature measurement per second
- Excellent stability against aging
Applications
Documentation
| Document title | Document type
|
Date Date | |
|---|---|---|---|
| PDF 865 KB | Datasheet | ||
| PDF 3.79 MB 日本語 | Application Note | ||
| PDF 2.87 MB 日本語 | Application Note | ||
| PDF 1.61 MB | Application Note | ||
| PDF 1.73 MB | Application Note | ||
| PDF 129 KB | Application Note | ||
| PDF 190 KB | Application Note | ||
| PDF 197 KB | Application Note | ||
| PDF 600 KB 日本語 | Overview | ||
| PDF 368 KB | Product Change Notice | ||
10 items
|
|||
Design & Development
Software & Tools
Software & Tools
| Software title
|
Software type
|
Company
|
|---|---|---|
| Sensor Software Modules for Renesas MCU Platforms Middleware (FIT module and FSP module) and sample software packages that enable control and data acquisition for Renesas sensor products.
|
Sensor | Renesas |
1 item
|
||
Sample Code
Sample Code
Filters
|
|||
|---|---|---|---|
| Title | Type | Date Date | |
|
[Software=FSP|v4.5.0;RX Driver Package|v1.35],[Toolchains=GNU ARM Embedded|v10.3.1.20210824;CC-RX|v3.02.00;GNURX|8.3.0.202004;CC-RL|v1.10.00;GNURL|4.9.2.202103;]
ZIP
52.85 MB
Application:
IoT Applications
Compiler:
CC-RL, CC-RX, GNU ARM Embedded, GNURL78, GNURX, ICCARM, ICCRL78, ICCRX
Function:
Application Example, Communication Interface
IDE:
e2 studio, IAR EWARM, IAR EWRL78, IAR EWRX
|
Sample Code | ||
|
ZIP
3.60 MB
Application:
IoT Applications
Function:
Application Example, Communication Interface, Driver or Library
|
Sample Code | ||
|
ZIP
3.74 MB
Application:
IoT Applications
Function:
Application Example, Communication Interface, Driver or Library
|
Sample Code | ||
|
ZIP
3.48 MB
Application:
IoT Applications
Compiler:
CC-RX, GNURX, ICCRX
Function:
Application Example, Communication Interface, Driver or Library
IDE:
CS+, e2 studio, IAR EWRX
|
Sample Code | ||
4 items
|
|||
Boards & Kits
Boards & Kits
HS4001 Relative Humidity and Temperature Sensor Evaluation Kit
The HS4000-EVK Evaluation Kit is used to assess the HS4001 High-Performance Relative Humidity and Temperature Sensor, with Digital I2C output. The hardware allows users...
Featured Documents:
Relative Humidity Sensor Pmod™ Board
The QCIOT-HS4001POCZ Board enables quick prototyping of the HS4001 High-Performance Relative Humidity and Temperature Sensor in a custom system design. The board...
Featured Documents:
Models
ECAD Models
Schematic symbols, PCB footprints, and 3D CAD models from SamacSys can be found by clicking on products in the Product Options table. If a symbol or model isn't available, it can be requested directly from the website.
Product Options
Processing table
| LGA | 8 | -40 to 125°C | Yes | Cut Tape | Get Samples, |
Tips for Using This Parametric Table:
- Hide Filters button in header: Collapse or expands filters
- Column sort buttons in header: Sort Column alphabetically / numerically descending or ascending
- Reset button in header: Reset all filters to the page default
- Full Screen button in header: Expand the table to full screen view (user must close out of full screen before they can interact with rest of page)
- Export button in header: Export the filtered results of the table to an Excel document
- Filter parts search bar in header: Type to filter table results by part number
- Hide column button in column headers: Select to hide columns in table
- AND / OR toggle switches in header: Toggles the logic of this particular filter to be “AND” or “OR” logic for filtering results
- Multiselect checkboxes at beginning of each row in table: Select these checkboxes to compare products against each other
- Document icon next to product name in row: View the featured document for this product
- Chip icon next to the right of the document icon in row: View the block diagram for this product
- Cart icon to the right of the chip icon: Indicates that samples are available for this product
