ルネサスは汎用のビデオおよびレシーバアプリケーション向けに設計されたRFアンプのポートフォリオを提供しています。 当社の高性能MMIC（モノリシックマイクロ波集積回路）シリコンバイポーラ差動アンプは、シングルエンドから差動へのコンバータとして使用でき、HDTVアンプ、衛星・地上波セットトップボックスのIFゲインブロック、衛星測位器や信号強度計など、幅広い汎用アプリケーションに最適です。

セレクションテーブル

    Processing table
    FMIN (MHz)
    FMAX (MHz)
    Frequency Range (MHz)
    IS (per amp) (mA)
    VS (Min) (V)
    VS (Max) (V)
    ZIN (ohms)
    ZOUT (ohms)
    Nch/Pch
    NF@1GHz (dBm)
    NF@2GHz (dB)
    OIP3@1GHz (dBm)
    OIP3 @ 1GHz Differential (dBm)
    S11@1GHz (-dB)
    S11 @ 1GHz Differential (-dB)
    S12@1GHz (-dB)
    S12 @ 1GHz Differential (-dB)
    S21@1GHz (-dB)
    S21 @ 1GHz Differential (-dB)
    S22@1GHz (-dB)
    S22 @ 1GHz Differential (-dB)
    Bandwidth (MHz)
    Lead Count (#)
    Pkg. Type
    型名
    ISL55014
    MMIC Silicon Bipolar Broadband Amplifier    		 500 3000 500 - 3000 63 3 V 5.5 V 50 50 4.3 30.3 20.8 22.2 17.2 12.8 2750 6 SC70
    ISL55033
    400MHz Slew Rate Enhanced Rail-to-Rail Output Gain Block    		 7.1 3 V 5.5 V 400 12 TQFN
