Renesas' multiplexing amplifiers feature high slew rate and excellent bandwidth for video switching applications such as set-top boxes, broadcast video equipment and HDTV/DTV analog inputs.

Analog Products

Product Selection Table

    Processing table
    Part Number
    Configuration
    Bandwidth (MHz)
    Slew Rate (V/µs)
    IS (mA)
    Gain Min
    IOUT (A)
    Diff Gain (%)
    Diff Phase (°)
    Lead Count (#)
    Pkg. Type
    EL4340
    500MHz Triple, Multiplexing Amplifier    		 Triple 2 to 1 500 870 30 1 0.135 0.02 0.02 24 QSOP
    ISL59446
    500MHz Triple 4:1 Gain-of-2, Multiplexing Amplifier    		 Triple 4 to 1 500 1600 44 1.94 0.135 0.008 0.01 32 QFN
