The IDT 89HP0602Q 2-Channel Multiprotocol Signal Repeater offers the industry a blend of top analog performance, lower power, and the most system level features in signal repeaters optimized for demanding 1.5Gbps to 6G applications in computing, storage, and communications.
Features
- 2 channel Multi-protocol signal repeater
- Advanced signal conditioning features
- Advanced diagnostic features
- Advanced power saving features
- Built-in mux/demux for Fail-Over support
- I2C programming interface
- Commercial and Industrial temperature
- Includes Evaluation Board - USB3
- Includes Evaluation Board - SATA
Design & Development
Software & Tools
Boards & Kits
Boards & Kits
Evaluation Board for 89HP0602Q USB3 Repeater, 1-lane, 5Gbps
The 89HP0602Q Repeater USB3 Evaluation Board is designed to enable quick in-system testing of IDT’s 2-channel, 6Gbps Repeater IC product for USB3...
Evaluation Board for 89HP0602Q SATA Repeater, 1-lane, 6Gbps
The 89HP0602Q Repeater SATA Evaluation Board is designed to enable quick in-system testing of IDT’s 2-channel, 6Gbps Repeater IC product for SATA...
