RX210

Renesas MCU Guide

Download the mobile app

Overview

The RX210 Group has a wide operating voltage range of 1.62 V to 5.5 V and can execute calculations at 78 DMIPS (Dhrystone million instructions per second) at up to 50 MHz high-speed operation. Furthermore, it achieves 0.2 mA/MHz low power performance when operating at 50 MHz. Consumption current in deep software standby mode is a mere 0.45 µA. A wide lineup of 48 KB to 1 MB ROM and 48-pin to 145-pin products is available.

Pin-Memory Diagram of RX210 stanndard products

Pin-Memory Diagram of RX210 High-temperature products

Applications

Consumer (battery drive)
Healthcare
Industrial
Home appliances
