Evaluation Board for 89HP0504P BGA Repeater, 16-lane, 5Gbps, PCIe2
The 89HP0504P Repeater Evaluation Board is designed to enable quick in-system testing of Renesas’s 4-channel, 5Gbps, PCIe 2.1 Repeater IC product.
This board...
概要
説明
The IDT 89HP0504P 4-channel PCIe Gen2 Repeater offers the industry a blend of top analog performance, lower power, and the most system level features in signal repeaters optimized for demanding 2.5Gbps to 5Gbps applications in computing, storage, and communications.
特長
- 4 channel PCIe Gen2 Signal Repeater
- Advanced signal conditioning features
- Advanced diagnostic features
- Advanced power saving features
- Built-in mux/demux for Fail-Over support
- I2C programming interface
- Commercial and Industrial temperature
ドキュメント
|
|
日付 | |
|---|---|---|
| PDF 1.38 MB | データシート | |
| PDF 422 KB | 概要 | |
| PDF 647 KB | EOL通知 | |
| PDF 898 KB | EOL通知 | |
| PDF 33 KB | デバイスエラッタ | |
| PDF 739 KB | アプリケーションノート | |
| PDF 200 KB | 製品概要 | |
| PDF 217 KB | 製品概要 | |
| PDF 110 KB | デバイスエラッタ | |
| PDF 236 KB | その他資料 | |
10 items
|
||
設計・開発
ソフトウェア／ツール
ボード＆キット
ボード＆キット
Evaluation Board for 89HP0504P (QFN) Repeater, 16-lane, 5Gbps PCIe2
The 89HP0504P (QFN) Repeater Evaluation Board is designed to enable quick in-system testing of Renesas’s 4-channel, 5Gbps, PCIe 2.1 repeater IC product.
This board...
Cable Evaluation Kit for 89HP0504P Repeater, 1-lane, 5Gbps PCIe2
The 89HP0504P (QFN2) Repeater cabling evaluation kit is a set of 2-boards designed to allow testing of PCIe2 cabled and mux/demux applications. There is a host...
